CCEC QSK38 Pump Engine

CCEC QSK38 series Pump Engine is V type 12-cylinder, 37.7 liters four-strokes engine with 159 mm (6.25 in) bore and 159 mm (6.25 in) stroke. CCEC QSK38 series Pump Engine equipped with PT Fuel System, comes with turbocharger. The prime power range of CCEC QSK38 series Pump Engine is from 1085 HP to 1600 HP (809 kW to 1193 kW). The torque range of the QSK38 Series Pump Engine is 4869 N.m to 6242 N.m.

To achieve different output, CCEC QSK38 series Pump engine have three configurations which are turbocharged engine, turbocharge with water-air intercooler, turbocharge with air-air intercooler. In the detailed model name, code T means engine come with turbocharger, code single A means engine comes with water-air intercooler, and code double A means engine comes with air-air intercooler. As part of EMAC, ConeMac provides pump power pack solution that integrated with air intake, air exhaust, cooling system, control system, transmission and hydraulic accessories, We also supplying special products such as explosion proof engine, generator and water pump set, as well as ultra-low temperature condition engine power pack.

General Specifications of QSK38 Series

Engine Type:6 Cylinders
Displacement:38 L
Rated Speed:1800 – 1900 RPM
Emission Standards:Euro I
Aspiration Method:Turbocharged & Water-Air Intercooler
Advertised Power:809 – 1193 kW @ 1800 – 1900 RPM
Peak Torque:4869 – 6242 N.m @ 1350 – 1500 RPM
Bore * Stroke:159 mm * 159 mm
Wet Weight:4842 kg
Dimension (L * W * H):2260 mm * 1339 mm * 2332 mm
CCEC QSK38 Pump Engine Catalogue

Engine Model

Rated Power

Peak Torque

Engine Model

Rated Power

Peak Torque

QSK38-P1085809 kW @ 1800 RPM4869 N.m @ 1350 RPMQSK38-P1086 810 kW @ 1800 RPM4869 N.m @ 1350 RPM
QSK38-P1200895 kW @ 1800 RPM5235 N.m @ 1400 RPMQSK38-P1260940 kW @ 1800 RPM5496 N.m @ 1400 RPM
QSK38-P13501007 kW @ 1800 RPM5858 N.m @ 1500 RPMQSK38-P15301140 kW @ 1800 RPM6242 N·m @ 1500 RPM
QSK38-P16001193 kW @ 1900 RPM6242 N.m @ 1500 RPM
——END——

CCEC QSK38 Series Pump Engine

This is the list of all series of CCEC QSK38 Series Pump Engine.
Click here to find industrial engines by type (Fuel System & Emission Standard).

QSK38-P1600 Pump Engine

QSK38-P1600 Pump Engine

Power: 1193 kW @ 1900 RPM
Fuel System: MCRS
Compression Ratio: 15 : 1
Aspiration: TC & Water-Air Intercooler
Emission Standard: U.S. EPA Tier 2

QSK38-P1530 Pump Engine

QSK38-P1530 Pump Engine

Power: 1141 kW @ 1800 RPM
Fuel System: MCRS
Compression Ratio: 15 : 1
Aspiration: TC & Water-Air Intercooler
Emission Standard: N/A

QSK38-P1350 Pump Engine

QSK38-P1350 Pump Engine

Power: 1007 kW @ 1800 RPM
Fuel System: MCRS
Compression Ratio: 15 : 1
Aspiration: TC & Water-Air Intercooler
Emission Standard: U.S. EPA Tier 2

QSK38-P1260 Pump Engine

QSK38-P1260 Pump Engine

Power: 940 kW @ 1800 RPM
Fuel System: MCRS
Compression Ratio: 15 : 1
Aspiration: TC & Water-Air Intercooler
Emission Standard: U.S. EPA Tier 2

QSK38-P1200 Pump Engine

QSK38-P1200 Pump Engine

Power: 895 kW @ 1800 RPM
Fuel System: MCRS
Compression Ratio: 15 : 1
Aspiration: TC & Water-Air Intercooler
Emission Standard: N/A

QSK38-P1086 Pump Engine

QSK38-P1086 Pump Engine

Power: 810 kW @ 1800 RPM
Fuel System: Cummins MCRS
Compression Ratio: 15 : 1
Aspiration: Turbocharged Aftercooled
Emission Standard: U.S. EPA Tier 2

QSK38-P1085 Pump Engine

QSK38-P1085 Pump Engine

Power: 809 kW @ 1800 RPM
Fuel System: MCRS
Compression Ratio: 15 : 1
Aspiration: TC & Water-Air Intercooler
Emission Standard: U.S. EPA Tier 2
