CCEC Generator Drive Engine

CCEC reliable and durable G-Drive diesel engine providing global G-OEMs with a cost-effective and fully integrated G-Drive product.

CCEC generator drive engines covering displacement from 10.8 to 50 liters, with power range from 175kW to 1582kW.

Multiple configurations can be provided to fit different performance level of Gen-set. The mechanical governor advantage is safety, stability and low-cost, it can meet G1 level; The electronic governor and ECM advantage provide accurate speed control, it can meet G2 & G3 and even higher requirement.As part of EMAC, SinoGen also provide complete power supply solutions that powered by CCEC our ranges of products including open type generator set, silence type generator set, super silence type generator set, mobile trailer, complete power truck and complete power car for railways applications. We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.

Advantages of G-Drive Engine

CCEC optimized the installation air filter system according to the engine structure, which reduced the outline dimension of Coolpac. Two filter to make sure that the filtration efficiency can reach 99.5%, it can avoid abnormal abrasion of the engine. Also we can provide the special type air filter system which can fit extreme applications, such as high altitude, dust or humidity.
Whether you need standby or emergency, continuous or prime power, you can rest assured there’s a CCEC G-Drive product to fit your application.

MTA11 G-Drive224 – 282 kW
NTA855 G-Drive205 – 407 kW
KTA19 G-Drive336 – 600 kW
KTA38 G-Drive560 – 1220 kW
KTA50 G-Drive1097 – 1650 kW
QSNT G-Drive358 – 545 kW
QSK19 G-Drive402 – 667 kW
QSK38 G-Drive876 – 1231 kW
QSK50 G-Drive1421 kW

Engine Model

Power/kW

040080012001600200024002800
Emission Srandard:Euro ⅠEuro ⅡEuro ⅢEuro ⅣEuro ⅤEuro ⅥEuro Ⅶ
CCEC G-Drive Engine Catalogue
Series
Model
MTA11-G2-A | 224 kW @ 1500 RPMMTA11-G2-B | 257 kW @ 1500 RPMMTA11-G2A | 234 kW @ 1500 RPMMTAA11-G3 | 282 kW @ 1500 RPM
NT855-G | 205 kW @ 1500 RPMNT855-GA | 231 kW @ 1500 RPMNTA855-G1-A | 240 kW @ 1500 RPMNTA855-G1-B | 287 kW @ 1500 RPM
NTA855-G1A | 264 kW @ 1500 RPMNTA855-G2A | 310 kW @ 1500 RPMNTA855-G1B | 284 kW @ 1500 RPMNTA855-G1B | 284 kW @ 1500 RPM
NTA855-G3 | 358 kW @ 1800 RPMNTA855-G4 | 317 kW @ 1500 RPMNTAA855-G7 | 343 kW @ 1500 RPMNTAA855-G7A | 300 HP @ 2200 RPM
KTA19-G2-A | 336 kW @ 1500 RPMKTA19-G2-B | 392 kW @ 1800 RPMKTA19-G3-A | 403 kW @ 1500 RPMKTA19-G3-B | 463 kW @ 1800 RPM
KTA19-G3A-A | 448 kW @1500 RPMKTA19-G3A-B | 507 kW @ 1800 RPMKTA19-G4-A | 448 kW @ 1500 RPMKTA19-G4-B | 507 kW @ 1800 RPM
KTA19-G8 | 575 kW @ 1500 RPMKTA19-G8A | 550 kW @ 1500 RPMKTA19-G8E | 500 kW @1500 RPMKTA19-G9A | 600 kW @ 1500 RPM
KTAA19-G5-A | 470 kW @ 1500 RPMKTAA19-G5-B | 533 kW @ 1800 RPMKTAA19-G6-A | 520 kW @1500 RPMKTAA19-G6-B | 831 kW @ 1800 RPM
KTAA19-G6A-A | 610 kW @ 1500 RPMKTAA19-G6A-B | 664 kW @ 1800 RPMKTAA19-G7-A | 610 kW @ 1500 RPMKTAA19-G7-B | 664 kW @ 1800 RPM
KT38-GA | 647 kW @ 1500 RPMKT38-G-A | 560 kW @ 1500 RPMKT38-G-B | 679 kW @ 1800 RPMKTA38-G1-A | 634 kW @ 1500 RPM
KTA38-G1-B | 769 kW @ 1800 RPMKTA38-G1B-A | 634 kW @ 1500 RPMKTA38-G1B-B | 769 kW @ 1800 RPMKTA38-G1E | 605 kW @ 1500 RPM
KTA38-G2-A | 664 kW @ 1500 RPMKTA38-G2-B |804 kW @ 1500 RPMKTA38-G2A-A | 813 kW @ 1500 RPMKTA38-G2A-B | 915 kW @ 1800 RPM
KTA38-G2B-A | 711 kW @ 1500 RPMKTA38-G2B-B | 830 kW @ 1500 RPMKTA38-G2E |715 kW @ 1500 RPMKTA38-G4| 1007 kW @ 1500 RPM
KTA38-G5 | 880 kW @ 1500 RPMKTA38-G5E | 825 kW @ 1500 RPMKTA38-G7E | 935 kW @ 1500 RPMKTA38-G9-A | 1195 kW @ 1500 RPM
KTA38-G9-B | 1220 kW @ 1500 RPMKTAA38-G9A | 1195 kW @ 1500 RPMKTA38-G9E | 990 kW @ 1500 RPM
KTA50-G3-A |1097 kW @ 1500 RPMKTA50-G3-B | 1220 kW @ 1500 RPMKTA50-G3E | 1210 kW @ 1500 RPMKTA50-G7E | 1210 kW @ 1500 RPM
KTA50-G8 | 1200 kW @ 1500 RPMKTA50-GS8 | 1725 kW @ 1500 RPMKTA50-G9 | 1384 kW @ 1800 RPMKTA50-G12-A | 1095 kW @ 1500 RPM
KTA50-G12-B | 1178 kW @ 1500 RPMKTA50-G12A-A | 1200 kW @ 1500 RPMKTA50-G12A-B | 1347 kW @ 1500 RPMKTA50-G15 | 1491 kW @ 1500 RPM
KTA50-G16 | 1200 kW @ 1500 RPM
QSNT-G3-A | 358 kW @ 1500 RPMQSNT-G3-B | 358 kW @ 1500 RPMQSNT-G4 | 407 kW @ 1500 RPMQSNT-G4X | 407 kW @ 1500 RPM
QSK19-G3-A |574 kW @ 1500 RPMQSK19-G3-B | 608 kW @ 1800 RPMQSK19-G4-A | 574 kW @ 1500 RPMQSK19-G4-B| 559 kW @ 1800 RPM
QSK19-G5 | 669 kW @ 1800 RPMQSK19-G11 | 500 kW @ 1500 RPMQSK19-G11X | 667 kW @ 1500 RPMQSK19-G12 | 670 kW @ 1500 RPM
QSK19-G13 | 406 kW @ 1500 RPMQSK19-G14| 362 kW @ 1500 RPMQSKTAA19-G3-NR2-A | 336 kW @ 1500 RPMQSKTAA19-G3-NR2-B | 670 kW @ 1500 RPM
QSK38-G1 | 1063 kW @ 1500 RPMQSK38-G4 | 1230 kW @ 1800 RPMQSK38-G5-A |1107 kW @ 1500 RPMQSK38-G5-B | 1063 kW @ 1500 RPM
QSK50-G7 | 1063 kW @ 1500 RPM
——END——

Find G-drive Engines by Series

This is the list of all series of CCEC G-drive engines.
Click here to find G-drive engines by type (Fuel System & Engine Speed).

MTAA11-G3 G-Drive Engine

MTAA11-G3 G-Drive Engine

Power: 282 kW / 1500 RPM @ 50 Hz
Fuel System: PT
Aspiration: TC & Charged Air Cooled Intercooler

KT38-G-B G-Drive Engine

KT38-G-B G-Drive Engine

Power: 1000 BHP (747 kW) @ 1800 RPM
Fuel System: PT
Aspiration: TC & Air – Air Intercooler

KTA38-G1E G-Drive Engine

KTA38-G1E G-Drive Engine

Power: 811 BHP (605 kW) @ 1500 RPM
Fuel System: CMA PT
Aspiration: TC & Water – Air Intercooler

KTA38-G2E G-Drive Engine

KTA38-G2E G-Drive Engine

Power: 959 BHP (715 kW) @ 1500 RPM
Fuel System: CMA PT
Aspiration: TC & Water – Air Intercooler

KTA38-G4 G-Drive Engine

KTA38-G4 G-Drive Engine

Power: 1350 BHP (1007 kW) @ 1800 RPM
Fuel System: CMA PT
Aspiration: TC & Water – Air Intercooler

KTA38-G5 G-Drive Engine

KTA38-G5 G-Drive Engine

Power: 1180 BHP (881 kW) @ 1500 RPM
Fuel System: CMA PT
Aspiration: TC & Water – Air Intercooler

KTA38-G5E G-Drive Engine

KTA38-G5E G-Drive Engine

Power: 1106 BHP (825 kW) @ 1500 RPM
Fuel System: CMA PT
Aspiration: TC & Water – Air Intercooler

KTA38-G7E G-Drive Engine

KTA38-G7E G-Drive Engine

Power: 1254 BHP (935 kW) @ 1500 RPM
Fuel System: CMA PT
Aspiration: TC & Water – Air Intercooler

KTAA38-G9A G-Drive Engine

KTAA38-G9A G-Drive Engine

Power: 1602 BHP (1195 kWm)@1500 RPM
Fuel System: PT(G)-EFC
Aspiration: TC & Air – Air Intercooler

KTA38-G9E G-Drive Engine

KTA38-G9E G-Drive Engine

Power: 1328 BHP (990 kW) @ 1500 RPM
Fuel System: CMS PT
Aspiration: TC & Water – Air Intercooler

KTA50-G9 G-Drive Engine

Power: 1855 BHP (1384 kW) @1800 RPM
Fuel System: CMA PT
Aspiration: TC & Low Temp. Aftercooled

QSNT-G3-A G-Drive Engine

QSNT-G3-A G-Drive Engine

Power: 358 kW (480 HP) @ 1500 RPM
Fuel System: CELECT
Aspiration: TC & Air-Air Intercooler
Emission Standard: STG IIIA, NRMM 3

QSNT-G3-B G-Drive Engine

QSNT-G3-B G-Drive Engine

Power: 358 kW (480 HP) @ 1800 RPM
Fuel System: CELECT
Aspiration: TC & Air-Air Intercooler
Emission Standard: STG IIIA, NRMM 3

QSNT-G4 G-Drive Engine

QSNT-G4 G-Drive Engine

Power: 407 kW (545 HP) @ 1500 RPM
Fuel System: CELECT
Aspiration: TC & Air-Air Intercooler
Emission Standard: N/A

QSNT-G4X G-Drive Engine

QSNT-G4X G-Drive Engine

ower: 407 kW (480 HP) @ 1500 RPM
Fuel System: CELECT
Aspiration: TC & Air-Air Intercooler
Emission Standard: N/A

QSK19-G12 G-Drive Engine

QSK19-G12 G-Drive Engine

Power: 675 HP (503 kW) at 1500 RPM
Fuel System: MCRS
Aspiration: TC & Low Temperature Aftercooled

QSK38-G1 G-Drive Engine

QSK38-G1 G-Drive Engine

Power: 1174 HP (876 kW) at 1500 RPM
Fuel System: CMS MCRS
Aspiration: TC & Low Temp Aftercooled
Emission Standard: U.S. EPA Tier 2

QSK38-G4 G-Drive Engine

QSK38-G4 G-Drive Engine

Power: 1650 HP (1231 kW) at 1800 RPM
Fuel System: CMS MCRS
Aspiration: TC & Low Temp Aftercooled
Emission Standard: U.S. EPA Tier 2

QSK38-G5-A G-Drive Engine

QSK38-G5-A G-Drive Engine

Power: 1484 HP (1107 kW) at 1500 RPM
Fuel System: CMS MCRS
Aspiration: TC & Aftercooled
Emission Standard: U.S. EPA Tier 2

QSK38-G5-B G-Drive Engine

QSK38-G5-B G-Drive Engine

Power: 1425 HP (1063 kW) at 1800 RPM
Fuel System: CMS MCRS
Aspiration: TC & Aftercooled
Emission Standard: U.S. EPA Tier 2

QSK50-G7 G-Drive Engine

Power: 1905 HP (1421 kW) at 1500 RPM
Fuel System: CMS
Aspiration: TC & Aftercooled
Emission Standard: U.S. EPA Tier 2
