CCEC QSK38-G5-B G-Drive Engine

CCEC QSK38-G5-B (1800 RPM) Generator Drive Engine is V Type 12-Cylinder, 37.7 liters (2301 in3) Four-Strokes Engine with 159 mm (6.25 in) Bore and 159 mm (6.25 in) Stroke.QSK38-G5-B Generator Drive Engine Equipped with CMI MCRS Fuel System, Comes with Turbocharged and Aftercooled.The Standby Power for 60 Hz Generator Set (1800 RPM) of CCEC QSK38-G5-B Generator Drive Engine is 1715 BHP (1279 kWm). The Prime Power for 60 Hz Generator Set (1800 RPM) of CCEC QSK38-G5-B Generator Drive Engine is 1425 BHP (1063 kWm).The Continuous Power for 60 Hz Generator Set (1800 RPM) of CCEC QSK38-G5-B Generator Drive Engine is 1195 BHP (891 kWm).

As Part of EMAC, SinoGen Also Provide Complete Power Supply Solutions that Powered by CCEC, Our Ranges of Products Including Open Type Generator Set, Silence Type Generator Set, Super Silence Type Generator Set, Mobile Trailer, Complete Power Truck and Complete Power Car for Railways Applications. We Provide Full Life Cycle Services for All Customers, From Design to Power System Supply, from Installation to Commissioning, from After-Sales Service Training to Spare Parts Supply, From Trouble Shooting to Overhaul Technical Support.

1. High quality alloy cast iron for the rigidity performance and lower vibration and noise. Wet and replaceable cylinder liners for better heat rejection performance and easier replacement.
2. 4 valves per cylinder, Optimize the mixed level which lead to an excellent fuel consumption rate and emis-sion performance. High quality alloy cast iron, one cylinder one head, single camshaft and special de-signed outine for better reliability and durability.
3. CMS unique PT with fixture and Step Timing control for precise fuel injection make the fuel injection pressure above 120Mpa, which leads to an ex-cellent fuel consumption rate and emission performance. Check valve in fuel tube improve reliability.
4. Gear water pump and great flux channel design pro-vide effective cooling. Spin-in water filter makes the coolant clean and keeps it in normal acidity.
5. Advanced Holset turbocharger and after-cooled technology, pulse exhaust manifold reduce exhaust temperature, provide excellence fuel consumption and emission performance.

Technical Specifications

 Basic Introduction of CCEC QSK38-G5-B  G-Drive Engine

Engine Model:QSK38-G5-B (-B means 1800 rpm engine)
Engine Type:Four Cycle; Vee; 12 Cylinder
Displacement:37.7 L
Rated Speed:1800 RPM
Aspiration Method:

Turbocharged and Aftercooled

Emission Standard:U.S. EPA Tier 2
Bore*Storke:159 mm * 159 mm
Packing Size(L*W*H):2220 mm * 1507 mm * 1846 mm
Dry Weight:4100 kg
Lead Time:15-30 Working Days
Payment Terms:T / T ,L / C
CCEC Generator Diver Engine 620×350 px-6

Engine Model

Prime Power

Aspiration

Configuration

Performance Curve

Compression Ratio

QSK38-G11174 HP (876 kW) at 1500 RPMTurbocharged and Low Temp AftercooledD233042GX03FR-678615:1
QSK38-G41650 HP (1231 kW)at 1800 RPMTurbocharged and Low Temp Aftercooled (2P/2L)D233042GX03FR-678915:1
QSK38-G5-A1484 HP (1107 kW)at 1500 RPMTurbocharged and AftercooledD233042GX03FR 679715:1
QSK38-G5-B1425 HP (1063 kW)at 1800 RPMTurbocharged and AftercooledD233042GX03FR 679715:1
——END——

General Infomation of CCEC QSK38-G5-B Generator Engine

Engine ModelQSK38-G5-BConfigurationD233042GX03
Performance CurveFR 6797CPL3573
TypeFour Cycle; Vee; 12 CylinderAspirationTurbocharged and Aftercooled
Stroke * Bore159 mm * 159 mm / 6.25 in * 6.25 inDisplacement2301 in3 / 37.7 L
Compression Ratio15:1No. of Cylinders6
Installation Diagram Number4954124Revision41876
Fuel SystemCMS MCRSEmissionsU.S. EPA Tier 2
Prime Power & Engine Speed1425 BHP (1063 kWm) at 1800 RPMContinuous Power & Engine Speed1195 BHP (891 kWm) at 1800 RPM
Standby Power & Engine Speed1715 BHP (1279 kWm) at 1800 RPM

Installation Data of CCEC QSK38-G5-B Generator Engine

Maximum Bending Moment at Rear Face of Block4500 lb.ft / 6101 N.mMaximum Static Loading at Rear Main Bearing2000 lb / 907 kg
Moment of Inertia of Rotating Components – with FW 6074 Flywheel93 inlbfsec2 / 10.4 kg.m2Moment of Inertia of Rotating Components – with FW 6077 Flywheel184 inlbfsec2 / 20.8 kg.m2
Center of Gravity from Rear Face of Block31.54 in / 801 mmCenter of Gravity Above Crankshaft Centerline6.8 in / 173 mm
Exhaust Noise at 1 m Horizontally from Centerline of Exhaust Pipe Outlet Upwards at 45°;1800 RPM96.3 dBASteady State Stability Band at Any Constant Load+/- 0.25%
Excludes Exhaust Noise; at Rated Load and7.5 m (24.6 ft); 1800 RPM99.4 Dba
——END——

Performance Data of CCEC QSK38-G5-B Generator Engine

PRIME POWERSTANDBYPRIME POWERSTANDBY
Frequency (Hz)6060Exhaust Gas Temperature (°F / °C)708 / 376750 / 400
Governed Engine Speed (RPM)18001800Exhaust Gas Flow (cfm / litre/s)8154 / 38499136 / 4312
Engine Idle Speed (RPM)700 – 900700 – 900Air to Fuel Ratio (air : fuel)33.3:130.9:1
Gross Engine Power Output (hp /kWm))1425 / 10631715 / 1279Radiated Heat to Ambient (BTU/min / kWm)5964 / 1057204 / 127
Brake Mean Effective Pressure (psi / kPa)316 / 2179328 / 2262Heat Rejection to Jacket Coolant (BTU/min / kWm)21804 / 38425783 / 453
Piston Speed (ft/min / m/s)1562 / 7.91562 / 7.9Heat Rejection to Exhaust (BTU/min / kWm)41725 / 73450176 / 882
Friction Horsepower (hp / kWm)115 / 86115 / 86Heat Rejected to Fuel (BTU/min / kWm)414 / 8414 / 8
Intake Air Flow (cfm / litre/s)3797 / 17934259 / 2010Heat Rejection to Aftercooler Coolant (BTU/min / Kw)18753 / 33023777 / 418
Engine Water Flow at Stated Friction Head External to Engine (4 psi Friction Head) (gpm / L/min)274 / 1037274 / 1037Aftercooler Water Flow at Stated Friction Head External to Engine(2 psi Friction Head) (gpm / L/min)168 / 636168 / 636
Engine Water Flow at Stated Friction Head External to Engine ( Maximum Friction Head ) (gpm / L/min)209 / 791209 / 791Aftercooler Water Flow at Stated Friction Head External to Engine(Maximum Friction Head) (gpm / L/min)150 / 568150 / 568


Performance Curve CCEC QSK38-G5 B G-Drive Engine

System Technical Data of CCEC QSK38-G5-B Generator Engine

Exhaust SystemMaximum back pressure at Standby Power2 in Hg / 7 kPa
Air Induction SystemMaximum Intake Air Restriction – with Dirty Filter Element25 in H2O / 6.2 kPa
Maximum Intake Air Restriction – with Normal Duty Air Cleaner and Clean Filter Element15 in H2O / 3.7 kPa
Cooling SystemJacket Water Circuit Requirements
Coolant Capacity — Engine112 quarts / 106 L
Coolant Capacity — Aftercoolers24 quarts / 22.7 L
Minimum Pressure Cap Rating at Sea Level11 psi / 76 kPa
Maximum Static Head of Coolant Above Engine Crank Centerline60 ft. / 18.3 m
Maximum Coolant Temperature (Max Top Tank Temp) for Standby/Prime Power220/212 deg F / 104/100 deg C
Thermostat (Modulating) Range180 – 202 deg F / 82 – 94 deg C
Maximum coolant friction head external to engine – 1800 RPM10 psi / 68.9 kPa
Aftercooler Circuit Requirements
Maximum Coolant Friction Head External to Engine – 1800 RPM10 psi / 68.9 kPa
Maximum Coolant Temperature into Aftercooler @ 77 °F (25 °C) Ambient120 °F / 49 °C
Maximum Coolant Temperature into Aftercooler @ Limiting Ambient Conditions for Standby/Prime power160/150 °F / 71/66 °C
Thermostat (Modulating) Range115 – 135 °F / 46 – 57 °C
Lubrication SystemOil Pressure @ Minimum Idle Speed20 PSI / 138 kPa
Oil Pressure @ Governed Speed50 – 70 PSI / 344.7 – 482.6 kPa
Maximum Oil Temperature248 °F / 120 °C
Oil Capacity with OP 6125 Oil Pan : Low – High37 – 44 gal / 140.1 – 166.6 L
Total System Capacity (Including Combo Filter)45 gal / 170.3 L
Fuel SystemType Injection SystemCMS MCRS
Maximum return fuel flow94 gal/hr / 356 L/hr
Maximum supply fuel flow159 gal/hr / 602 L/hr
Maximum fuel inlet temperature160 deg F / 71 deg C
Maximum fuel supply restriction at fuel pump inlet – with dirty fuel filter element(s) at maximum fuel flow10 in-Hg / 34 kPa
Maximum fuel supply restriction at fuel pump inlet – with clean fuel filter element(s) at maximum fuel flow5 in-Hg / 16.9 kPa
Electrical SystemSystem Voltage24 volt
Maximum Starting Circuit Resistence0.002 ohm
Minimum Recommended Battery Capacity – cold soak at 10 deg C (50 deg F) and above1800 0°F CCA
Minimum Recommended Battery Capacity – cold soak at 0 to 10 deg C (32 to 50 deg F)1800 0°F CCA
Minimum Recommended Battery Capacity – cold soak at -18 to 0 deg C (0 to 32 deg F)1800 0°F CCA
——END——

Scopes of Supply of CCEC QSK38-G5-B Generator Drive Engine

Air Intake System1. Air Intake ManifoldExhuast System1. Exhuast Manifold
2. Standard Air Filter2. Turbocharger
3. Water-Air Intercooler3. Exhuast Elbow
Starting System1. Starter MotorCharging System1. Charging Alternator
2. Starter Rely2. N/A
Lubricating System1. Oil PumpCooling System1. Water Pump
2. Oil Filter2. Engine Fan
3. N/A3. Standard Radiator
Engine Shut-Down System1. Engine Fuel Shut-Off SolenoidPower Output System1. Flywheel
2. N/A2. Standard Flywheel Housing
Fuel System1. Fuel Transfer Pump
2. High-Pressure Fuel Pump
3. Fuel Filter
——END——

Optional Accessories of CCEC QSK38-G5-B Generator Drive Engine

Air Intake System1. Air Intake Pre-HeaterExhuast System1. Muffler & Bellows
2. Air Intake Shut-Off Valve2. Spark Arrestor Type Muffler & Bellows
3. Heavy-Duty Air Filter3. DPF System
4. Plateau Type Air Filter4. N/A
Fuel System1. Coarse FilterLubricating System1. Oil Pre-Heater
2. Fuel Pre-Heater2. N/A
Starting System1. Manual Magnetic DC ContactorCooling System1. Silent Type Radiator
2. Dual Ears Flywheel Housing2. Plateau Radiator
3. Spring Starter Motor3. Salt-Spray Resistant Radiator
4. Air Starter Motor4. Coolant Pre-Heater
5. Hydraulic Starter Motor5. Jacket Water Heater
6. Manual Magnetic DC Contactor6. N/A
——END——

As part of EMAC, SinoGen focusing on generator set related business, from Generator drive engine power pack to complete generator set, from generator control panel to synchronizing cabinet, from super silent type generator set to mobile power trailer, SinoGen provides professional one-stop solution for everything customer needed for generator set.
For more information of our complete generator set products, you are welcome to visit SinoGen homepage: www.sino-gen.com

Modifiable components of QSK38-G5-B Generator Drive Engine

Air Intake System1. Installation Position of Air FilterCharging System1. 12V Charging Alternator for 12V Electric System
2. Upgrade to Heavy-Duty Type Air Fitler2. Explosion-Proof Charging Alternator
Exhuast System1. Position of TurbochargerLubricating System1. Oil Pan Position
2. Water-Cooled Exhuast Manifold2. Number of Dipstick
3. Water-Cooled Turbocharger3. Position of Dipstick
Fuel System1. Upgrade to Fuel Fitler that Integrated with Fuel Transfer PumpStarting System1. 12V Starter Motor for 12V Electric System
Engine Shut-Down System1. 12V Solenoid for 12V Electric SystemPower Output System1. Size of Flywheel Housing and Flywheel.
2. Explosion-Proof Solenoid2. Dual-Ear Flywheel Housing (For Twin-Starter System)
——END——

Note: All Above Data are Just for Referenece, All Data Might Change Without Notices or Update, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
