CCEC KTA38 Marine Auxiliary Engine
CCEC K38-DM series marine auxiliary engine is V Type 12-cylinder, 38 liters four-strokes engine with 159 mm (6.25 in) bore and 159 mm (6.25 in) stroke. CCEC K38-DM series marine auxiliary engine equipped with PT Fuel System, comes with turbocharger. The power range of CCEC K38-DM series marine auxiliary engine is from 750 HP to 1350 HP (560 kW to 1007 kW). The torque range of the K38-DM Series marine auxiliary engine is 3921 N.m to 6175 N.m.
CCEC marine auxiliary engines have different configurations which have different power output, with code T in the engine model name means turbocharged engine, code TA in the engine model means turbocharge with water-air intercooler and code TAA in the engine model means turbocharge with air-air intercooler. All CCEC marine auxiliary engine are comes with dry type exhaust system, which means dry type exhaust manifold and dry type turbocharger, SeaMac provides upgrading services for water-cooled exhaust system, which modify dry type exhaust system into water-cooled exhaust system, which are quite important and often requested by passenger boat projects.
General Specifications of KTA38 Series
Engine Type: | V-12 Cylinders / 4 Stroke / 4 Valve |
Displacement: | 38 L |
Bore * Stroke: | 159 mm * 159 mm |
Advertised Power: | 560 – 1007 kW @ 1500 – 1800 RPM |
Peak Torque: | 3921 – 6175 N.m @ 1500 – 1800 RPM |
Rated Speed: | 1500 – 1800 RPM |
Emissision: | Euro II |
Aspiration Method: | Turbocharged & Water – Air Intercooler |
Dry Weight: | 3723 kg |
Dimission Standards: | 2210 mm * 1320 mm * 1651 mm |
CCEC KTA38 Marine Auxiliary Engine Catalogue | ||||||
Engine Model | Rated Power | Aspiration | Engine Model | Rated Power | Aspiration | |
K38 – DM746 | 746 kW (1000 HP) @ 1500 RPM | LTA | K38 – DM821 | 821 kW (1100 HP) @ 1800 RPM | LTA | |
K38 – DM880 | 880 kW (1180 HP) @ 1500 RPM | Water-Air Intercooler | K38 – DM969 | 969 kW (1300 HP) @ 1800 RPM | Water-Air Intercooler | |
KT38 – D(M)560 | 560 kW (750 HP) @ 1500 RPM | Turbocharged | KT38 – D(M)679 | 679 kW (910 HP) @ 1800 RPM | Turbocharged | |
KTA38 – D(M)664 | 664kW (890 HP) @ 1500 RPM | Water – Air Intercooler | KTA38 – D(M)768 | 768 kW (1030 HP) @ 1800 RPM | Water – Air Intercooler | |
KTA38 – D(M)809 | 809 kW (1085 HP) @ 1800 RPM | Water – Air Intercooler | KTA38 – D(M)814 | 814 kW (1092 HP) @ 1800 RPM | Water – Air Intercooler | |
KTA38 – D(M)880 | 880 kW (1180 HP) @ 1500 RPM | Water – Air Intercooler | KTA38 – D(M)1007 | 1007 kW (1350 HP) @ 1800 RPM | Water – Air Intercooler | |
——END—— |
CCEC KTA38 Series Marine Auxiliary Engine
This list including all models of CCEC KTA38 Series Marine Auxiliary Engine.
Click here to find marine engines by type (Fuel System & Power Range).
KTA38 – D(M)1007 Auxiliary Engine
Power: 1007 kW (1350 HP) @ 1800 RPM
Rating Type: Prime Power
Fuel System: PT
Aspiration: TC & Water-Air Intercooler
Emission Standard: N/A
K38 – DM746 Auxiliary Engine
Power: 746 kW (1000 HP) @ 1500 RPM
Rating Type: Prime Power
Fuel System: PT
Aspiration: Turbocharged / LTA
Emission Standard: N/A
K38 – DM821 Auxiliary Engine
Power: 821 kW (1100 HP) @ 1800 RPM
Rating Type: Prime Power
Fuel System: Direct Injection CMI PT
Aspiration: Turbocharged / LTA
Emission Standard: N/A
K38 – DM880 Auxiliary Engine
Power: 880 kW (1180 HP) @ 1500 RPM
Rating Type: Prime Power
Fuel System: Direct Injection CMI PT
Aspiration: TC & Water-Air Intercooler
Emission Standard: N/A
K38 – DM969 Auxiliary Engine
Power: 969 kW (1300 HP) @ 1800 RPM
Rating Type: Prime Power
Fuel System: Direct Injection CMI PT
Aspiration: TC & Water-Air Intercooler
Emission Standard: N/A
KT38 – D(M)560 Auxiliary Engine
Power: 560 kW (750 HP) @ 1500 RPM
Rating Type: Prime Power
Fuel System: PT
Aspiration: Turbocharged
Emission Standard: N/A
KT38 – D(M)679 Auxiliary Engine
Power: 679 kW (910 HP) @ 1800 RPM
Rating Type: Prime Power
Fuel System: PT
Aspiration: Turbocharged
Emission Standard: N/A
KTA38 – D(M)664 Auxiliary Engine
Power: 880 kW (1180 HP) @ 1500 RPM
Rating Type: Prime Power
Fuel System: PT
Aspiration: TC & Water-Air Intercooler
Emission Standard: N/A
KTA38 – D(M)768 Auxiliary Engine
Power: 768 kW (1030 HP) @ 1800 RPM
Rating Type: Prime Power
Fuel System: PT Pump
Aspiration: TC & Water-Air Intercooler
Emission Standard: N/A
KTA38 – D(M)809 Auxiliary Engine
Power: 809 kW (1085 HP) @ 1800 RPM
Rating Type: Prime Power
Fuel System: PT
Aspiration: TC & Water-Air Intercooler
Emission Standard: N/A
KTA38 – D(M)814 Auxiliary Engine
Power: 814 kW (1092 HP) @ 1800 RPM
Rating Type: Prime Power
Fuel System: PT Pump
Aspiration: TC & Water-Air Intercooler
Emission Standard: N/A
KTA38 – D(M)880 Auxiliary Engine
Power: 880 kW (1180 HP) @ 1500 RPM
Rating Type: Prime Power
Fuel System: PT
Aspiration: TC & Water-Air Intercooler
Emission Standard: N/A
