CCEC NTA855 Generator Drive Engine

CCEC NTA855 series generator drive engine is 6-cylinder inline, 14 liter four-strokes engine with 140 mm (5.5 in) bore and 152 mm (6.0 in). CCEC NTA855 generator drive engine equipped with PT Fuel System, comes with turbocharger.

The prime power range for 50HZ generator set (1500RPM) of CCEC NTA855 series generator drive engine is from 205 kW to 407 kW.

The prime power range for 60HZ generator set (1800RPM) of CCEC NTA855 series generator drive engine is from 287 kW to 358 kW.

CCEC generator drive engines have different configurations which have different power output, with code T in the engine model name means turbocharged engine, code TA in the engine model means turbocharge with water-air intercooler and code TAA in the engine model means turbocharge with air-air intercooler. We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.

Advantages of NTA855 G-Drive Engine

·Durable
Cylinder block and cylinder head adopt integrated design, low failure rate, excellent lubrication system, low parasitic power, durability and excellent reputation.
·Adaptable
Wide range of oil products and strong environmental adaptability.
·Good Reliability
CMI’ advanced PT fuel system has unique overspeed protection, low pressure fuel supply, less pipelines and low failure rate. Originating from excellent overall design, it has excellent reliability.
·Easy Maintenance
Overall modular design, block integration, compact structure, parts can be split. High reusability.

CCEC NTA855 – Drive Engine Catalogue

Engine Model

Rated Power

Aspiration

Engine Model

Rated Power

Aspiration

NT855-G
275 HP (205 kW) at 1500 RPMTurbochargedNT855-GA
310 HP (231 kW) at 1500 RPMTurbocharged
NTA855-G1-A
322 HP (240 kW) at 1500 RPM
 Aftercooled IntercoolerNTA855-G1-B
386 HP (287 kW) at 1800 RPM Aftercooled Intercooler
NTA855-G1A
350 HP (264 kW) at 1500 RPM Aftercooled IntercoolerNTA855-G1B
380 HP (284 kW) at 1500 RPM
 Aftercooled Intercooler
NTA855-G2-A
380 HP (284 kW) at 1500 RPM Aftercooled IntercoolerNTA855-G2-B
420 HP (313 kW) at 1800 RPM Aftercooled Intercooler
NTA855-G2A
415 HP (310 kW) at 1500 RPM Aftercooled IntercoolerNTA855-G3
480 HP (358 kW) at 1800 RPM Aftercooled Intercooler
NTA855-G4
425 HP (317 kW) at 1500 RPM Aftercooled IntercoolerNTAA855-G7
460 HP (343 kW) at 1500 RPM Air – Air Intercooler
NTAA855-G7A
545 HP (407 KW) at 1500 PRM Air – Air Intercooler
——END——

CCEC NTA855 Series G-Drive Engine

This list including all models of CCEC NTA855 Series G-Drive Engine.
Click here to find G-drive engines by type (Fuel System & Engine Speed).

CCEC NTA855-G3 G-Drive Engine

CCEC NTA855-G3 G-Drive Engine

Power: 480 HP (358 kW) at 1800 RPM
Fuel System: PT
Aspiration: TC & Water – Air Intercooler
Emission Standard: N/A

CCEC NTA855-G4 G-Drive Engine

CCEC NTA855-G4 G-Drive Engine

Power: 425 HP (317 kW) at 1500 RPM
Fuel System: PT
Aspiration: TC & Water – Air Intercooler
Emission Standard: N/A
