CCEC QSK38 Generator Drive Engine

CCEC QSK38 series generator drive engine is V Type 12-cylinder, 37.7 liters four-strokes engine with 159 mm (6.25 in) bore and 159 mm (6.25 in) stroke. CCEC QSK38 generator drive engine equipped with PT Fuel System, comes with turbocharger.

The prime power range for 50HZ generator set (1500RPM) of CCEC QSK38 series generator drive engine is from 876 kW to 1107 kW.

The prime power range for 60HZ generator set (1800RPM) of CCEC QSK38 series generator drive engine is from 1063 kW to 1231 kW.

CCEC generator drive engines have different configurations which have different power output, with code T in the engine model name means turbocharged engine, code TA in the engine model means turbocharge with water-air intercooler and code TAA in the engine model means turbocharge with air-air intercooler. We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.

Advantages of QSK38 G-Drive Engine

·Easy Maintenance
Overall modular design, block integration, compact structure, detachable parts, high reusability.
·Adaptable
High pressure fuel pump, Modular Common Rail Fuel System (MCRS) and advanced ECM control system make the product highly adaptable to altitude, temperature and load.
·Good Durability
Two-stage fuel filtration and pre-lubrication technology reduce engine wear and increase durability. Extended service intervals are available with CentriguardTM centrifugal filters and CENTINELTM continuous oil renewal systems.

CCEC QSK38 – Drive Engine Catalogue

Engine Model

Rated Power

Aspiration

Engine Model

Rated Power

Aspiration

QSK38-G11174 HP (876 kW) at 1500 RPM Low Temp AftercooledQSK38-G41650 HP (1231 kW) at 1800 RPM Low Temp Aftercooled (2P/2L)
QSK38-G5-A1484 HP (1107 kW) at 1500 RPM  AftercooledQSK38-G5-B1425 HP (1063 kW) at 1800 RPM Aftercooled
——END——

CCEC QSK38 Series G-drive Engine

All models of CCEC QSK38 Series G-drive Engine.
Click here to find G-drive engines by type (Fuel System & Engine Speed).

QSK38-G1 G-Drive Engine

QSK38-G1 G-Drive Engine

Power: 1174 HP (876 kW) at 1500 RPM
Fuel System: CMS MCRS
Aspiration: TC & Low Temp Aftercooled
Emission Standard: U.S. EPA Tier 2

QSK38-G4 G-Drive Engine

QSK38-G4 G-Drive Engine

Power: 1650 HP (1231 kW) at 1800 RPM
Fuel System: CMS MCRS
Aspiration: TC & Low Temp Aftercooled
Emission Standard: U.S. EPA Tier 2

QSK38-G5-A G-Drive Engine

QSK38-G5-A G-Drive Engine

Power: 1484 HP (1107 kW) at 1500 RPM
Fuel System: CMS MCRS
Aspiration: TC & Aftercooled
Emission Standard: U.S. EPA Tier 2

QSK38-G5-B G-Drive Engine

QSK38-G5-B G-Drive Engine

Power: 1425 HP (1063 kW) at 1800 RPM
Fuel System: CMS MCRS
Aspiration: TC & Aftercooled
Emission Standard: U.S. EPA Tier 2
