CCEC X15 Industrial Engine

CCEC X15 series industrial engines have excellent performance characteristics. It has a 17.2 : 1 compression ratio, displaces 912 cubic inches (14.9 liters) , and offers a wide rpm range, including a maximum low idle speed of 1,200 rpm and a minimum low idle speed of 700 rpm. In addition, the engine adopts XPI fuel system, combined with turbocharging and charge air cooling system, to ensure efficient combustion and excellent performance. Its main power range is 106 HP to 535 HP (79 kW to 399 kW), and the torque range is 1825 N.m to 2644 N.m.

In order to give users a better experience, CCEC X15 series industrial engines are equipped with an excellent crankshaft system (cold start capability) and an excellent cooling system to ensure that the engine can start reliably and efficiently under different environmental conditions, thus improving reliability and efficiency. ,Environmental friendly. In addition, a good lubrication system also provides better cooling, reduced friction, extended life and increased efficiency for the machine.

As part of EMAC, ConeMac provides industrial power pack solution that integrated with air intake, air exhaust, cooling system, control system, transmission and hydraulic accessories, We also supplying special products such as explosion proof engine, generator and water pump set, as well as ultra-low temperature condition engine power pack.

Coming Soon

Coming Soon

Coming Soon

General Specifications of X15 Series

Engine Type:4 Cycle , In-line , 6 Cylinder
Displacement:15 L
Rated Speed:1800 – 2100 RPM
Emission Standards:EU Stage II – EU Stage IIIA
Aspiration Method:Turbocharged Charge-Air-Cooled
Advertised Power:375 – 535 HP @ 2100 RPM
Peak Torque:1825 – 2644 N.m @ 1400 RPM
Bore * Stroke:137 mm * 169 mm
Dry Weight:1343 kg
Dimension (L * W * H):1712 mm * 1067 mm * 1234 mm
CCEC X15 Industrial Engine Catalogue

Engine Model

Rated Power

Peak Torque

Engine Model

Rated Power

Peak Torque

X15-C535535 HP @ 2100 RPM2644 N.m @ 1400 RPMQSX15-C375375 HP @ 1800 RPM1825 N.m @ 1400 RPM
QSX15-C525525 HP @ 2100 RPM2440 N.m @ 1400 RPMQSX15-C530530 HP @ 1800 RPM2365 N.m @ 1400 RPM
——END——

CCEC QSX15 Series Industrial Engine

This is the list of all series of CCEC X15 Series Industrial Engine.
Click here to find industrial engines by type (Fuel System & Emission Standard).

QSX15-C375 Industrial Engine ( Imported )

QSX15-C375 Industrial Engine ( Imported )

Rated Power: 375 HP @ 1800 RPM
Max. Torque: N/A
Fuel System: HPI Electronic
Aspiration: Turbocharged CAC
Emission Standard: CARB Tier 3, EU Stage IIIA, US EPA Tier 3

QSX15-C525 Industrial Engine ( Imported )

QSX15-C525 Industrial Engine ( Imported )

Rated Power: 525 HP @ 2100 RPM
Max. Torque: N/A
Fuel System: HPI Electronic
Aspiration: Turbocharged CAC
Emission Standard: U.S. EPA Tier 2, CARB Tier 2, EU Stage II

QSX15-C530 Industrial Engine ( Imported )

QSX15-C530 Industrial Engine ( Imported )

Rated Power: 530 HP @ 1800 RPM
Max. Torque: N/A
Fuel System: HPI Electronic
Aspiration: Turbocharged CAC
Emission Standard: U.S. EPA Tier 2, CARB Tier 2, EU Stage II
