CQ19-291 Pump Engine
CCEC CQ19-291 (1800 RPM) Pump Engine is V type 6-cylinder, 18.9 liters four-strokes engine with 159 mm (6.25 in) bore and 159 mm (6.25 in) stroke.
CQ19-291 Pump Engine equipped with CCEC PT Fuel System, comes with turbocharger and Air-to Air Cooled, with a EURO II post-processor. The Advertised power at 1800 RPM of CCEC CQ19-291 Pump Engine is 809 HP (604 kW). The maximum torque of the engine at 1800 RPM is 3523 N.m.
As part of EMAC, ConeMac provides pump power pack solution that integrated with air intake, air exhaust, cooling system, control system, transmission and hydraulic accessories, We also supplying special products such as explosion proof engine, generator and water pump set, as well as ultra-low temperature condition engine power pack.
We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.
Advantages of CCEC CQ19-291 Pump Engine
-
Powerful and Consistent Output. It uses turbocharged and air-to-air intercooled aspiration with a 4-stroke in-line 6-cylinder design, delivering strong power for long continuous heavy-load tasks, meeting high-demand operation needs.
-
Efficient Fuel Economy. Equipped with Cummins PT fuel system, it optimizes fuel injection to ensure thorough combustion, keeping fuel consumption low and cutting down long-term operational fuel costs effectively.
-
Strong Environmental Adaptability. No fuel adjustments are needed at altitudes up to 1525 m and temperatures below 38℃; only minor tweaks are required in extreme high-altitude or high-temperature conditions for stable performance.
-
Reliable Cooling Performance. Its intercooler and thermostat work together to control intake air and coolant temperatures precisely, preventing overheating even during prolonged high-load operation, ensuring engine safety.
-
Stable Lubrication Protection. The lubrication system maintains steady oil pressure and flow, with a bypass filter and large oil pan to keep oil clean and sufficient, reducing component wear and extending service life.
-
It meets UL certification and 10% speed governing requirements, with minimal speed fluctuations under constant load, suitable for scenarios needing steady power like generator sets.
Technical Specifications
Basic Introduction of CCEC CQ19-291 Pump Engine
| Engine Model: | CQ19-291 |
| Engine Type: | 4 Cycle , In-line , 6 Cylinder |
| Displacement: | 18.9 L |
| Rated Speed: | 1800 RPM |
| Rated Power / Speed: | 604 kW @ 1800 RPM |
| Aspiration Method: | Turbocharged, Air-to Air Cooled |
| Emission Standard: | U.S. EPA Tier 2 |
| Bore * Stroke: | 159 mm * 159 mm |
| Packing Size (L * W * H): | N / A |
| Wet Weight: | 7055 kg |
| Lead Time: | 15-30 Working Days |
| Payment Terms: | T/T ,L/C |
General Information of CCEC CQ19-291 Pump Engine |
|||
| Engine Model | CQ19-291 | Emission Standard | U.S. EPA Tier 2 |
| Advertised Power | 809 HP (604 kW) @ 1800 RPM | Peak Torque | 2599 lb ft (3523 N.m) @ 1800 RPM |
| Curve & DatAsheet | FR 291 | Governed Power | 890 HP (664 kW) @ 1800 RPM |
| Compression Ratio | 13.9 : 1 | Packing Size (L * W * H) | N / A |
| Type | 4 Cycle , In-line , 6 Cylinder | Displacement | 1150 in³ ( 18.9 L ) |
| Fuel System | Cummins PT | Bore * Stroke | 6.25 in * 6.25 in / 159 mm * 159 mm |
| Aspiration | Turbocharged, Air-to Air Cooled | Minimum Low Idle Speed | N/A |
| Configuration | D193108GX03 | Maximum Low Idle Speed | 1980 RPM |
| CPL Code | 3959 | Minimum speed for full load sustained operation | N/A |
General Engine Data of CCEC CQ19-291 Pump Engine |
|||
| Aspiration | Turbocharged, Air-to Air Cooled | Wet Weight | 7055 lb / 3200 kg |
| Bore * stroke | 6.25*6.25in. / 159*159 (mm) | Moment of Inertia of Rotating Components (Excluding Flywheel) | 43.2 lbₘ·ft² / 1.82 kg·m² |
| Displacement | 1150 in³ / 18.9 L | C.G. Distance From Rear Face of Block | 28.4 in / 721 mm |
| Compression Ratio | 13.9:1 | C.G. Distance Above Crank Centerline | 9.0 in / 229 mm |
| Dry Weight | 6614 lb / 3000 kg | Firing Order | 1-5-3-6-2-4 |
Engine Mounting Data of CCEC CQ38E-259 Pump Engine |
|||
| Maximum Allowable Bending Moment at Rear Face of Block | 1000 lb.ft / 1356 N.m | ||
| ——END—— | |||
Performance Data of CCEC CQ19-291 Pump Engine |
|||
| Stability at Any Invariables Load | ±0.25% | Maximum No-Load Governed Speed | 1980 r/min |
| Engine Speed | 1800 r/min | Gross Power Output | 890 HP (664 kW) |
| Brake Mean Effective Pressure | 338 PSI (2333 kPa) | Piston Speed | 1870 ft/min (10 m/s) |
| Friction Horsepower | 83 HP (62 kW) | Inlet Air Flow | 2051 CFM (968 L/s) |
| Exhaust Gas Flow (Wet Manifold) | 5630 CFM (2657 L/s) | Exhaust Gas Temperature (Wet Manifold) | 936 °F (502 °C) |
| Heat Rejection to Ambient (Wet Manifold) | 5402 BTU/min (95 kW) | Heat Rejection to Coolant (Wet Manifold) | 27012 BTU/min (475 kW) |
| Engine Water Flow U.S.GPM(L/s)@4psi(27.5kPa) | 197 (12.4) | ||
| ——END—— | |||
| System Technical Data of CCEC CQ19-518 Pump Engine | ||
| Air Induction System | Maximum Allowable Intake Air Restriction With Heavy Duty Air Cleaner (Clean Element) | 15 in H₂O / 3.73 kPa |
| Maximum Allowable Intake Air Restriction With Heavy Duty Air Cleaner (Dirty Element) | 25 in H₂O / 6.23 kPa | |
| Intake Air Temperature Before Cooler | 392 °F / 200 °C | |
| Outlet Air Temperature After Cooler | 131 °F / 55 °C | |
| Heat Rejection to Cooler | 8360 BTU/min / 147 kW | |
| Recommended Intake Piping Size (Inner Diameter) | 6.0 in / 152 mm | |
| Exhaust System | Maximum Allowable Back Pressure | 3.0 in Hg / 10.0 kPa |
| Cooling System | Coolant Capacity (Engine Only) | 7 U.S Gal / 26.5 L |
| Standard Thermostat Modulating Range | 180-200 °F / 82-93 °C | |
| Maximum Coolant Pressure (Exclusive of Pressure Cap) | 17 PSI / 1103 kPa | |
| Minimum Allowable Pressure Cap @Sea Level | 5 PSI / 48 kPa | |
| Maximum Pressure Drop Across Any External Cooling System Circuit | 5 PSI / 34.5 kPa | |
| Maximum Allowable Top Tank Temperature | 212 °F / 100 °C | |
| Minimum Coolant Makeup Capacity | 1.6 U.S Gal / 6.1 L | |
| Maximum Raw Water Inlet Friction | 10 mm Hg / 254 in Hg | |
| Minimum Allowable Fill Rate | 5 U.S GPM / 18.9 L/min | |
| Minimum Allowable Coolant Expansion Space | 5% of System Capacity | |
| Maximum Allowable Deaeration Time | 25 min | |
| Cooling System Type | 2 Pump 2 Loop | |
| Lubrication System | Oil Pressure @Idle | 20 PSI / 138 kPa |
| Oil Pressure @Rated Speed | 50-70 PSI / 345-483 kPa | |
| Oil Flow at Rated Speed | 40 U.S GPM / 151.4 L/min | |
| Maximum Allowable Oil Temperature | 250 °F / 121.0 °C | |
| By-Pass Filter Capacity (Spin-on Cartridge Type) | 0.7 U.S Gal / 2.65 L | |
| Oil Pan Capacity (Option OP4020) – Low | 8.5 U.S Gal / 32.2 L | |
| Total System Capacity (Excluding By-Pass Filter) | 13.2 U.S Gal / 50 L | |
| Angularity of Standard Oil Pan (Option OP4020) – Front Down | 30° | |
| Angularity of Standard Oil Pan (Option OP4020) – Front Up | 30° | |
| Fuel System | Maximum Allowable Restriction to PT Fuel Pump (With Clean Fuel Filter) | 4 in Hg / 13.55 kPa |
| Maximum Allowable Restriction to PT Fuel Pump (With Dirty Fuel Filter) | 8 in Hg / 27.09 kPa | |
| Maximum Allowable Injector Return Line Restriction (With Check Valves) | 6.5 in Hg / 22 kPa | |
| Maximum Allowable Injector Return Line Restriction (Less Check Valves) | 2.5 in Hg / 8.5 kPa | |
| Minimum Allowable Fuel Tank Vent Capability (With 2.5 in Hg (8.4kPa) or Less Back Pressure) | 15 ft³/h / 425 L/h | |
| Maximum Fuel Supply Temperature (Measured at On-Engine Fuel Inlet Fitting) | 160 °F / 71 °C | |
| Electrical System | Starter (Heavy Anode) Voltage | 24 Volt |
| Battery Recharge System, Negative Ground | 100 A | |
| Maximum Allowable Resistance of Starting Circuit | 0.002 Ω | |
| Minimum Recommended Battery Capacity (Cold Soak at 0-32°F (-18-0°C) or Above) – 0°F CCA | 900 | |
| ——END—— | ||
Scopes of Supply of CCEC CQ19-518 Pump Engine |
||||
| Air Intake System | 1. Air Intake Manifold | Exhuast System | 1. Exhuast Manifold | |
| 2. Water-air Intercooler | 2. Turbocharger | |||
| 3. N/A | 3. Exhuast Elbow | |||
| Fuel System | 1. Fuel transfer pump | Starting System | 1. Starter motor | |
| 2. High-pressure fuel pump | 2. Starter rely | |||
| 3. Fuel Filter | 3. N/A | |||
| Charging System | 1. Charging alternator | Engine Shut-Down System | 1. Engine fuel shut-off solenoid | |
| Lubricating System | 1. Oil pump | Cooling System | 1. Water pump | |
| 2. Oil filter | 2. Engine Fan | |||
| 3. N/A | 3. Standard radiator | |||
| Power Output System | 1. Flywheel | Engine Mounting System | 1. Engine Mouting Bracket | |
| 2. Standard flywheel housing | 2. N/A | |||
| Engine Auiliary Accessories | 1. Air compressor | |||
| 2. Power steering pump | ||||
| ——END—— | ||||
Optional Accessories of CCEC CQ19-518 Pump Engine |
||||
| Air Intake System | 1. Air Intake pre-heater | Exhuast System | 1. Muffler & bellows | |
| 2. Air intake shut-off valve | 2. Flame trap | |||
| 3. Air filter | 3. Spark arrestor type Muffler & bellows | |||
| 4. Air intake pre-filter | 4. DPF system | |||
| 5. Air filter alarm system | 5. N/A | |||
| Fuel System | 1. Coarse Filter | Starting System | 1.Manual Magnetic DC Contactor | |
| 2. Fuel pre-heater | 2. Dual ears flywheel housing | |||
| 3. N/A | 3. Spring Starter Motor | |||
| 4. N/A | 4. Air Starter Motor | |||
| 5. N/A | 5. Hydraulic Starter Motor | |||
| Lubricating System | 1. Oil pre-heater. | Cooling System | 1. Silent Type Radiator | |
| 2. N/A | 2. Plateau Radiator | |||
| 3. N/A | 3. Salt-Spray Resistant Radiator | |||
| 4. N/A | 4. Coolant pre-heater | |||
| Power Output System | 1. Clutch | Engine Mounting System | 1. Shock absorber pad | |
| Engine Auiliary Accessories | 1. Hydraulic oil pump | Control System | 1. Can add mechanical accelerator pedal | |
| 2. Air conditioner compressor | 2. N/A | |||
| 3. N/A | 3. N/A | |||
| ——END—— | ||||
As part of EMAC, PumpMac focusing on water pump set related business, from pump drive engine, to WPT PTO, from complete engine power pack to complete water pump set, from NFPA20 standard fire fighting pump accessories to fire pump drive package, from explosion proof accessories to complete explosion-proof water pump set, PumpMac provides professional one-stop solution for everything customer needed for water pump set industry.
For more information of our pump drive power pack and complete water pump set products, you are welcome to visit PumpMac homepage: www.pumpmac.com
Modifiable Components of CCEC CQ19-518 Pump Engine |
||||
| Air Intake System | 1. Installation position of air filter | Exhuast System | 1. Can modify installation position and direction of | |
| 2. Upgrade to heavy-duty type air fitler | turbocharger | |||
| 3. N/A | 2. Water-cooled exhuast manifold | |||
| 4. N/A | 3. Water-cooled turbocharger | |||
| Fuel System | 1. Upgrade to fuel fitler that integrated with fuel transfer | Starting System | 1. 12 V starter motor for 12 v electric system | |
| pump and fuel pre-hearter | 2. Upgrading to specified brand and speicifications of | |||
| 2. N/A | starter motor | |||
| Charging System | 1. 12 V charging alternator for 12 v electric system | Engine Shut-Down System | 1. 12 V solenoid for 12 v electric system | |
| 2. Explosion-proof charging alternator | 2. Explosion-proof solenoid | |||
| 3. Upgrading to specified brand and speicifications of | 3. N/A | |||
| charging alternator | 4. N/A | |||
| Lubricating System | 1. Oil Pan position | Cooling System | 1. Can modify engine fan into blower fan or suction fan | |
| 2. Number of dipstick | 2. Can modify central position of engine cooling fan | |||
| 3. Position of dipstick can choose from 6 positions | 3. Can choose type of engine fan from mechanical type or | |||
| 4. Can modify oil filter to be remote installation | electric type | |||
| Power Output System | 1. Can modify size of flywheel housing and flywheel. | Engine Mounting System | 1. Can modify engine mouting bracket. | |
| 2. Dual-ear flywheel housing (For twin-starter system) | 2. N/A | |||
| 3. Some of models can modify flywheel housing into PTO | 3. N/A | |||
| integrated type. | 4. N/A | |||
| 4. Engine have connecting port of PTOs, that able to | 5. N/A | |||
| provide power output. | 6. N/A | |||
| Engine Auiliary Accessories | 1. All of auxiliary system can choose specified brands and | |||
| specifications. | ||||
| 2. Additional auxiliary systems can be added for special | ||||
| applications. | ||||
| ——END—— | ||||
Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
