NTA855 Marine
CCEC NTA855-M series marine main engine is 6-cylinder inline, 14 liters four-strokes engine with 140 mm (5.5 in) bore and 152 mm (6.0 in) stroke. CCEC NTA855-M series marine main engine equipped with PT Fuel System, comes with turbocharger. The prime power range of CCEC NTA855-M series marine main engine is from 220 HP to 450 HP (164 kW to 336 kW). The torque range of the NTA855-M Series marine main engine is 1044 N.m to 2612 N.m.
CCEC marine main engines have different configurations which have different power output, with code T in the engine model name means turbocharged engine, code TA in the engine model means turbocharge with water-air intercooler and code TAA in the engine model means turbocharge with air-air intercooler. Based on standard DCEC marine main engines, SeaMac provides both heat exchanger cooling and keel cooling marine main engines. SeaMac provides full life cycle services for all our customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.
Advantages of NTA855 Marine Engine
·High Reliability NT series marine engine has stable performance, sufficient combustion, low failure rate, fast starting, good acceleration, strong cooling, high injection pressure, perfect detection characteristics, good transient response, high reliability and durability. ·Emission Advantage It meets the requirements of IMO TIER2 emission regulations, and adopts CMI high-efficiency supercharger and high-efficiency intercooler to make the engine run efficiently, and the application of low-temperature intercooler technology greatly reduces fuel consumption and emissions, while enhancing engine reliability.
NTA855 Mechanical Marine Main Engine
NT855-M147 Marine Engine
Power: 110 kW (147 HP) @ 1600 RPM
Rating Type: Continuous
Fuel System: PT
Aspiration: Turbocharged
Emission Standard: N/A
NT855 – M200 Marine Engine
Power: 149 kW (200 HP) @ 1800 RPM
Rating Type: Continuous
Fuel System: PT
Aspiration: Turbocharged
Emission Standard: N/A
NT855 – M220 Marine Engine
Power: 164 kW (220 HP) @ 1800 RPM
Rating Type: Continuous
Fuel System: PT
Aspiration: Turbocharged
Emission Standard: N/A
NT855 – M240 Marine Engine
Power: 179 kW (240 HP) @ 1800 RPM
Rating Type: Continuous
Fuel System: PT
Aspiration: Turbocharged
Emission Standard: N/A
NT855 – M250 Marine Engine
Power: 187 kW (250 HP) @ 1800 RPM
Rating Type: Continuous
Fuel System: PT
Aspiration: Turbocharged
Emission Standard: N/A
NT855 – M270 Marine Engine
Power: 201 kW (270 HP) @ 1800 RPM
Rating Type: Continuous
Fuel System: PT
Aspiration: Turbocharged
Emission Standard: N/A
NT855 – M300 Marine Engine
Power: 224 kW (300 HP) @ 1800 RPM
Rating Type: Continuous
Fuel System: PT
Aspiration: Turbocharged
Emission Standard: N/A
NTA855 – M350 Marine Engine
Power: 261 kW (350 HP) @ 1800 RPM
Rating Type: Continuous
Fuel System: PT
Aspiration: TC & Water – Air Intercooler
Emission Standard: N/A
NTA855 – M400A Marine Engine
Power: 298 kW (400 HP) @ 1800 RPM
Rating Type: Continuous
Fuel System: PT
Aspiration: TC & Water – Air Intercooler
Emission Standard: N/A
NTA855 – M400B Marine Engine
Power: 298 kW (400 HP) @ 2100 RPM
Rating Type: Continuous
Fuel System: PT
Aspiration: TC & Water – Air Intercooler
Emission Standard: N/A
NTA855 – M450 Marine Engine
Power: 336 kW (450 HP) @ 1800 RPM
Rating Type: Continuous
Fuel System: PT
Aspiration: TC & Water – Air Intercooler
Emission Standard: N/A
