CCEC QSK38 Generator Drive Engine
CCEC QSK38 series generator drive engine is V Type 12-cylinder, 37.7 liters four-strokes engine with 159 mm (6.25 in) bore and 159 mm (6.25 in) stroke. CCEC QSK38 generator drive engine equipped with PT Fuel System, comes with turbocharger.
The prime power range for 50 Hz generator set (1500 RPM) of CCEC QSK38 series generator drive engine is from 876 kW to 1107 kW.
The prime power range for 60 Hz generator set (1800 RPM) of CCEC QSK38 series generator drive engine is from 1063 kW to 1231 kW.
CCEC generator drive engines have different configurations which have different power output, with code T in the engine model name means turbocharged engine, code TA in the engine model means turbocharge with water-air intercooler and code TAA in the engine model means turbocharge with air-air intercooler. We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.
General Specifications of QSK38 Series
| Engine Type: | Four Cycle; Vee; 12 Cylinder |
| Displacement: | 38 L |
| Rated Speed: | 1500 – 1800 RPM |
| Emission Standard: | Euro II |
| Fuel System: | CMS MCRS |
| Standby Power: | 970 – 1376 kW @ 1500 – 1800 RPM |
| Prime Power: | 876 – 1231 kW @ 1500 – 1800 RPM |
| Bore * Stroke: | 159 mm * 159 mm |
| Dry Weight: | 3825 – 4100 kg |
| Packing Size (L * W * H): | 2220 mm * 1507 mm * 1846 mm |
| CCEC QSK38 – Drive Engine Catalogue | |||||||
Engine Model | Rated Power | Aspiration | Engine Model | Rated Power | Aspiration | ||
| QSK38-G1 | 1174 HP (876 kW) at 1500 RPM | Low Temp Aftercooled | QSK38-G4 | 1650 HP (1231 kW) at 1800 RPM | Low Temp Aftercooled (2P/2L) | ||
| QSK38-G5-A | 1484 HP (1107 kW) at 1500 RPM | Aftercooled | QSK38-G5-B | 1425 HP (1063 kW) at 1800 RPM | Aftercooled | ||
| ——END—— | |||||||
CCEC QSK38 Series G-drive Engine
All models of CCEC QSK38 Series G-drive Engine.
Click here to find G-drive engines by type (Fuel System & Engine Speed).
QSK38-G1 G-Drive Engine
Power: 1174 HP (876 kW) at 1500 RPM
Fuel System: CMS MCRS
Aspiration: TC & Low Temp Aftercooled
Emission Standard: U.S. EPA Tier 2
QSK38-G4 G-Drive Engine
Power: 1650 HP (1231 kW) at 1800 RPM
Fuel System: CMS MCRS
Aspiration: TC & Low Temp Aftercooled
Emission Standard: U.S. EPA Tier 2
QSK38-G5-A G-Drive Engine
Power: 1484 HP (1107 kW) at 1500 RPM
Fuel System: CMS MCRS
Aspiration: TC & Aftercooled
Emission Standard: U.S. EPA Tier 2
QSK38-G5-B G-Drive Engine
Power: 1425 HP (1063 kW) at 1800 RPM
Fuel System: CMS MCRS
Aspiration: TC & Aftercooled
Emission Standard: U.S. EPA Tier 2
