QSK23-C760 Industrial Engine ( Imported )
CCEC QSK23-C760 Industrial Engine have excellent performance characteristics. It has a compression ratio of 16 : 1, a displacement of 1,413 cubic inches (23.2 liters)
CCEC QSK23-C760 Industrial Engine offers a wide rev range, including a maximum low idle speed of 1,800 rpm and a minimum low idle speed of 1,350 rpm. In addition, the engine adopts HPI CELECT fuel system, with both turbocharging and charge air cooling system, ensuring efficient combustion and excellent performance.
As part of EMAC, ConeMac provides industrial power pack solution that integrated with air intake, air exhaust, cooling system, control system, transmission and hydraulic accessories, We also supplying special products such as explosion proof engine, generator and water pump set, as well as ultra-low temperature condition engine power pack.
We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.
Advantages of CCEC QSK23-C760 Industrial Engine
-
Lower oil consumption, Extended stroke, the expansion of the combustion gas more fully, Increase effective efficiency output, the economy is better.
-
High power output, QSK23-C760 has excellent power output and is suitable for various heavy-duty industrial applications, such as large generator sets, mining equipment, construction machinery, etc. Its high power characteristics can meet various high-load working requirements.
-
Excellent reliability, with compulsive cold cut articulated pistons, Can bear extreme high mechanical load and heat load, Strength can be comparable with heavy engine.
-
Better emissions, Decorate injector and symmetrical combustion chamber in center, make the cylinder is more homogeneous mixture, burning more fully, lower emissions.
-
Super life, 30 % engines 800,000 km without overhaul.
-
Excellence power, Clean burning, use the advanced lean-burn closed loop electronic control system.
-
Reliability and Durability, QSK23-C760 has undergone Cummins’ strict quality control and testing and has excellent reliability and durability, capable of continuous operation in various harsh environmental conditions.
Technical Specifications
Basic Introduction of CCEC QSK23-C760 Industrial Engine
| Engine Model: | QSK23-C760 |
| Engine Type: | 6 Cylinders |
| Displacement: | 23.2 L |
| Rated Speed: | 1800 RPM |
| Rated Power / Speed: | 760 HP @ 1800 RPM |
| Aspiration Method: | Turbocharged Charge-Air-Cooled |
| Fuel System: | HPI Celect |
| Bore * Stroke: | 170 mm x 170 mm |
| Packing Size (L * W * H): | 2885 mm * 1656 mm * 2029 mm |
| Weight , Net Dry: | 3185 kg |
| Lead Time: | 15-30 Working Days |
| Payment Terms: | T/T ,L/C |
| Engine Model | Rated Power | Displacement | Aspiration | Compression Ratio | Fuel System |
| QSK23-C760 | 760 HP @ 1800 RPM | 1,413 in3 (23.2 L) | Turbocharged and Charge Air Cooled | 16 : 1 | HPI Celect |
| QSK23-C860 | 860 HP @ 2100 RPM | 1,413 in3 (23.2 L) | Turbocharged & Charge Air Cooled | 16 : 1 | HPI Electronic |
| —END— | |||||
| General Information of CCEC QSK23-C760 Industrial Engine | |||
| Engine Model | QSK23-C760 | CPL Code | 2858 |
| Curve & Datasheet | FR5381 | Rated Power | 760 HP (567 kW) @ 1800 RPM |
| Compression Ratio | 16 : 1 | Torque Peak | 2,558 lb-ft (3,468 N-m) @ 1350 RPM |
| Noise Emissions Top Side | N/A | Revision | 2-March-2017 |
| Noise Emissions Right Side | 105 dBa | Displacement | 1413 in3(23.2 L) |
| Noise Emissions Left Side | 105 dBa | Fuel System | HPI Celect |
| Noise Emissions Front Side | 103 dBa | Maximum low idle speed | 1200 RPM |
| Emission Certification | Non-certified | Minimum low idle speed | 750 RPM |
| Aspiration | Turbocharged and Charge Air Cooled | Minimum engine speed for full load sustained operation | 1550 RPM |
| Configuration | D893008CX03 | Maximum continuous power | N/A |
| Maximum overspeed capability | N/A | Maximum continuous speed | N/A |
| —END— | |||
| Torque Output | Power Output | Fuel Consumption | ||||||
| RPM | lb-ft | N-m | RPM | HP | kW | RPM | lb/hp-hr | g/kW-hr |
| 850 RPM | 1338 lb-ft | 1814 N-m | 850 RPM | 216 HP | 161 kW | 850 RPM | 0.358 lb/hp-hr | 218 g/kW-hr |
| 900 RPM | 1460 lb-ft | 1980 N-m | 900 RPM | 251 HP | 187 kW | 900 RPM | 0.355 lb/hp-hr | 216 g/kW-hr |
| 1000 RPM | 1705 lb-ft | 2312 N-m | 1000 RPM | 325 HP | 242 kW | 1000 RPM | 0.354 lb/hp-hr | 216 g/kW-hr |
| 1100 RPM | 1949 lb-ft | 2642 N-m | 1100 RPM | 408 HP | 304 kW | 1100 RPM | 0.343 lb/hp-hr | 209 g/kW-hr |
| 1200 RPM | 2192 lb-ft | 2972 N-m | 1200 RPM | 500 HP | 373 kW | 1200 RPM | 0.331 lb/hp-hr | 202 g/kW-hr |
| 1300 RPM | 2436 lb-ft | 3303 N-m | 1300 RPM | 603 HP | 450 kW | 1300 RPM | 0.325 lb/hp-hr | 197 g/kW-hr |
| 1350 RPM | 2558 lb-ft | 3468 N-m | 1350 RPM | 657 HP | 490 kW | 1350 RPM | 0.324 lb/hp-hr | 197 g/kW-hr |
| 1400 RPM | 2515 lb-ft | 3410 N-m | 1400 RPM | 671 HP | 500 kW | 1400 RPM | 0.322 lb/hp-hr | 196 g/kW-hr |
| 1500 RPM | 2431 lb-ft | 3296 N-m | 1500 RPM | 695 HP | 518 kW | 1500 RPM | 0.324 lb/hp-hr | 197 g/kW-hr |
| 1600 RPM | 2357 lb-ft | 3196 N-m | 1600 RPM | 717 HP | 535 kW | 1600 RPM | 0.325 lb/hp-hr | 198 g/kW-hr |
| 1700 RPM | 2284 lb-ft | 3097 N-m | 1700 RPM | 739 HP | 551 kW | 1700 RPM | 0.326 lb/hp-hr | 198 g/kW-hr |
| 1800 RPM | 2218 lb-ft | 3007 N-m | 1800 RPM | 760 HP | 567 kW | 1800 RPM | 0.325 lb/hp-hr | 198 g/kW-hr |
| —END— | ||||||||
| Engine Performance Data CCEC QSK23-C760 Industrial Engine | ||||
| Governed Power | Peak Torque | |||
| Engine Speed | 1800 RPM | 1350 RPM | ||
| Output Power | 760 HP | 567 kW | 657 HP | 490 kW |
| Torque | 2218 lb-ft | 3007 N-m | 2558 lb-ft | 3468 N-m |
| Friction Horsepower | N/A | N/A | N/A | N/A |
| Intake Manifold Pressure | 54 in-Hg | 181 kPa | 38 in-Hg | 130 kPa |
| Turbo Comp. Outlet Pressure | 58 in-Hg | 195 kPa | 41 in-Hg | 137 kPa |
| Turbo Comp. Outlet Temperature | 331 deg F | 166 deg C | 279 deg F | 137 deg C |
| Inlet Air Flow | 1693 ft3/min | 799 L/s | 1138 ft3/min | 537 L/s |
| Exhaust Gas Flow | 3829 ft3/min | 1807 L/s | 3030 ft3/min | 1430 L/s |
| Exhaust Gas Temperature | 783 deg F | 417 deg C | 948 deg F | 509 deg C |
| Heat Rejection to Coolant | 11374 BTU / min | 200 kW | 9952 BTU / min | 175 kW |
| Heat Rejection to Ambient | 3981 BTU / min | 70 kW | 3412 BTU / min | 60 kW |
| Heat Rejection to Exhaust | 24624 BTU / min | 433 kW | 22179 BTU / min | 390 kW |
| —END— | ||||
| System Technical Data of CCEC QSK23-C760 Industrial Engine | |||
| Intake Air System | Maximum allowable air temperature rise over ambient at Intake Manifold (Naturally Aspirated Engines) or Turbo Compressor inlet (Turbo-charged Engines): (This parameter impacts emissions, LAT and/or altitude capability) |
20 delta deg F | 11.1 delta deg C |
| Cooling System | Maximum intake manifold temperature at 25 deg C (77 F) ambient | 140 deg F | 60 deg C |
| Maximum allowable pressure drop across charge air cooler and OEM CAC piping (IMPD) | 4 in-Hg | 13.5 kPa | |
| Maximum Intake Manifold Temperature Differential (Ambient to IMT) (IMTD): | 63 delta deg F | 35.0 delta deg C | |
| Intake manifold temperature for full Fan-ON | 122 deg F | 50 deg C | |
| Maximum coolant temperature for engine protection controls | 221 deg F | 105 deg C | |
| Maximum coolant operating temperature at engine outlet (max. top tank temp) | 212 deg F | 100 deg C | |
| Exhaust Syetem | Maximum exhaust back pressure: | 2.96 in-Hg | 10 kPa |
| Recommended exhaust piping size (inner diameter): | 7.99 in | 203 mm | |
| Lubrication System | Nominal operating oil pressure minimum low idle | 14.9 psi | 103 kPa |
| Nominal operating oil pressure maximum rated speed | 65.0 psi | 448 kPa | |
| Minimum engine oil pressure for engine protection devices minimum low idle | 7 ps | 48 kPa | |
| Fuel System | Fuel cooling requirements (with diesel fuel) | ||
| Maximum heat rejection to return fuel at max. coolant and inlet fuel temperature: | 1024 BTU/min | 18 Kw | |
| fuel return flow rate of | 1301 lb/hr | 590 kg/hr | |
| fuel return temperature prior to cooler: | 279 deg F | 137 deg C | |
| Maximum supply fuel flow | 1479 lb/hr | 671 kg/hr | |
| Maximum return fuel flow: | 1301 lb/hr | 590 kg/hr | |
| Engine fuel compatibility (consult Service Bulletin #5411406 for appropriate use of other fuels) | DF1, DF2 | ||
| Maximum fuel inlet pressure: | 3 psi | 21 kPa | |
| Cranking System (Cold Starting Capability) | Unaided Cold Start Minimum cranking speed | 100 RPM | |
| Minimum ambient temperature for unaided cold start | 18 deg F | -7.8 deg C | |
| Cranking torque at minimum unaided cold start temperature | 724 lb-ft | 982 N-m | |
| Aided Cold Start Minimum ambient temperature with Grid Heater only | -9 deg F | -23 deg C | |
| Cold starting aids available | Intake Manifold Heater, None, None, NoneNone | ||
| Maximum parasitic load at 10 deg F @ | |||
| —END— | |||
Scopes of Supply of CCEC QSK23-C760 Industrial Engine |
||||
| Fuel System | 1. Fuel Transfer Pump | Exhaust System | 1. Exhuast Manifold | |
| 2. High-Pressure Fuel Pump | 2. Turbocharger | |||
| 3. Fuel Filter | 3. Exhuast Elbow | |||
| Air Intake System | 1. Air Intake Manifold | Starting System | 1. Starter Motor | |
| 2. N/A | 2. Starter Relay | |||
| Cooling System | 1. Water Pump | Power Output System | 1. Flywheel | |
| 2. Engine Fan | 2. Standard Flywheel Housing | |||
| 3. Standard Radiator | 3. N/A | |||
| Lubricating System | 1. Oil Pump | Charging System | 1. Charging Alternator | |
| 2. Oil Filter | 2. N/A | |||
| Engine Shut-Down System | 1. Engine Fuel Shut-Off Solenoid | Engine Mounting System | 1. Engine Mounting Bracket | |
| Engine Auiliary Accessories | 1. Air Compressor | |||
| ——END—— | ||||
Optional Accessories of CCEC QSK23-C760 Industrial Engine |
||||
| Air Intake System | 1. Air Intake Pre-Heater | Exhuast System | 1. Muffler & Bellows | |
| 2. Air Intake Shut-Off Valve | 2. Flame Trap | |||
| 3. Air Filter | 3. Spark Arrestor Type Muffler & Bellows | |||
| 4. Air Intake Pre-Filter | 4. Dpf System | |||
| 5. Air Filter Alarm System | 5. N/A | |||
| Fuel System | 1. Coarse Filter | Lubricating System | 1. Oil Pre-Heater. | |
| 2. Fuel Pre-Heater | 2. N/A | |||
| Starting System | 1. Manual Magnetic Dc Contactor | Cooling System | 1. Silent Type Radiator | |
| 2. Dual Ears Flywheel Housing | 2. Plateau Radiator | |||
| 3. Spring Starter Motor | 3. Salt-Spray Resistant Radiator | |||
| 4. Air Starter Motor | 4. Coolant Pre-Heater | |||
| 5. Hydraulic Starter Motor | 5. Jacket Water Heater | |||
| 6. Manual Magnetic Dc Contactor | 6. N/A | |||
| Engine Auiliary Accessories | 1. Hydraulic Oil Pump | Control System | 1. Can Add Engine Monitoring System, Contro System With Wiring Harness. | |
| 2. Air Conditioner Compressor | 2. Can Add Self-Protection System that Integrated with Alarm System. | |||
| Power Output System | 1. Clutch | Engine Mounting System | 1. Shock Absorber Pad | |
| ——END—— | ||||
Committed to Providing Stable and Reliable Premiem Power System for Global Construction Machinery Manufacturer Partners, ConeMac is A Sub-Brand of the EMAC Group that Focuses on Construction Equipment Application.
ConeMac’s Ranges of Products Mainly Inclduing Marine Construction Engines Power Pack, Construction Equipment Gearbox, Gear Reducer, Explosion-Proof Engines, Generator Set and Water Pump Set for Mining, Oil and Gas Field.
For More Information of Our Industrial Power System Products, You Are Welcome to Visit ConeMac Homepage: Conemac.cn
Modifiable Components of CCEC QSK23-C760 Industrial Engine
|
||||
| Air Intake System | 1. Installation Position of Air Filter | Charging System | 1. 12 V Charging Alternator for 12 v Electric System | |
| 2. Upgrade to Heavy-Duty Type Air Fitler | 2. Explosion-Proof Charging Alternator | |||
| 3. N/A | 3. Upgrading to Specified Brand and Speicifications of Charging Alternator | |||
| Exhuast System | 1. Water-Cooled Exhuast Manifold | Lubricating System | 1. Oil Pan Position | |
| 2. Water-Cooled Turbocharger | 2. Number of Dipstick | |||
| 3. Can Modify Installation Position and Direction of Turbocharger | 3. Position of Dipstick Can Choose from 6 Positions | |||
| 4. N/A | 4. Can Modify Oil Filter to be Remote Installation | |||
| Engine Shut-Down System | 1. 12 V Solenoid for 12 V Electric System | Starting System | 1. Upgrading to Specified Brand and Speicifications of Starter Motor | |
| 2. Explosion-Proof Solenoid | 2. 12 V Starter Motor for 12 V Electric System | |||
| Fuel System | 1. Upgrade to Fuel Fitler that Integrated with Fuel Transfer Pump and Fuel Pre-Hearter | Engine Auiliary Accessories | 1. All of auxiliary System can Choose Specified Brands and Specifications | |
| 2. N/A | 2. Additional Auxiliary Systems Can be Added for Special Applications | |||
| Cooling System | 1. Can Modify Engine fan Into Blower Fan or Suction Fan | Power Output System | 1. Can Modify Size of Flywheel Housing and Flywheel | |
| 2. Can Modify Central Position of Engine Cooling Fan | 2. Dual-Ear Flywheel Housing (For Twin-Starter System) | |||
| 3. Can Choose Type of Engine Fan From Mechanical Type or Electric Type | 3. Some of Models can Modify Flywheel Housing Into PTO Integrated Type | |||
| 4. N/A | 4. Engine Have Connecting Port of PTOs, That Able to Provide Power Output | |||
| Engine Mounting System | 1. Can Modify Engine Mouting Bracket | |||
| ——END—— | ||||
Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
