CCEC NTA855 Pump Drive Engine
CCEC NT855 Series Pump Drive Engine is a 6-cylinder inline, 14 liters four-strokes engine with 140 mm (5.5 in) bore and 152 mm (6.0 in) stroke. NT855 Series Pump Drive Engine equipped with PT Fuel System, comes with turbocharger. The power range of CCEC NT855 series pump drive engine is from 300 HP to 500 HP (224 kW to 373 kW). The torque range of the NT855 Series Pump Drive Engine is 1051 N.m to 2233 N.m.
EMAC is a partner of CCEC for many years, we are a professional pump system solution supplier with many years of experience. We provide customers from all over the world with one-stop pump system solutions from pump system design to pump system supply, from installation to commissioning, and from after-sales. Providing sales service support for spare parts supply, EMAC is your reliable pump system partner, providing you with the best value for money and reliable system solutions.
General Specifications of NTA855 Series
| Engine Type: | 4 Cycle , 6 Cylinder |
| Displacement: | 14 L |
| Rated Speed: | 1500 – 2100 RPM |
| Rated Power / Speed: | 224 – 373 kW @ 1500 – 2100 RPM |
| Peak Torque: | 1460 – 1831 N.M @ 1300 – 1500 RPM |
| Fuel System: | CMI PT / PT / PT – STC |
| Aspiration Method: | Turbocharged & Water-Air Intercooler |
| Bore * Stroke: | 140 mm * 152 mm |
| Basic Engine (L * W * H): | 2142 mm * 1067 mm * 1733 mm |
| Dry Weight: | 1143 – 2970 kg |
Engine Model | Rated Power | Peak Torque | Engine Model | Rated Power | Peak Torque | |
| NT855-P300 | 224 kW (300 HP) @ 1500 RPM | 1051 N.m @ 1500 RPM | NT855-P300B | 224 kW (300 HP) @ 1500 RPM | 1356 N.m @ 1300 RPM | |
| NT855-P360 | 269 kW (360 HP) @ 1800 RPM | 1536 N.m @ 1300 RPM | NT855-P400 | 298 kW (400 HP) @ 1800 RPM | 1625 N.m @ 1300 RPM | |
| NTA855-P360 | 269 kW (360 HP) @ 2100 RPM | 1536 N.m @ 1300 RPM | NTA855-P360B | 269 kW (360 HP) @ 1800 RPM | 1536 N.m @ 1300 RPM | |
| NTA855-P360C | 268 kW (360 HP) @ 2100 RPM | 1464 N.m @ 1500 RPM | NTA855-P400A | 298 kW (400 HP) @ 1500 RPM | 1625 N.m @ 1300 RPM | |
| NTA855-P400B | 299 kW (400 HP) @ 1800 RPM | 1460 N.m @ 1400 RPM | NTA855-P400C | 298 kW (400 HP) @ 2100 RPM | 1627 N.m @ 1400 RPM | |
| NTA855-P450 | 336 kW (450 HP) @ 1800 RPM | 1783 N.m @ 1800 RPM | NTA855-P450B | 336 kW (450 HP) @ 2100 RPM | 1831 N.m @ 1400 RPM | |
| NTA855-P470 | 351 kW (470 HP) @ 1500 RPM | 1627 N.m @ 1400 RPM | NTA855-P470B | 351 kW (470 HP) @ 1500 RPM | 2233 N.m @ 1500 RPM | |
| NTA855-P500 | 373 kW (500 HP) @ 1800 RPM | 1356 N.m @ 1800 RPM | NTA855-P500B | 373 kW (500 HP) @ 1800 RPM | 2069 N.m @ 1800 RPM | |
| ——END—— | ||||||
CCEC NTA855 Series Pump Drive Engine
This list including all models of CCEC NTA855 Series Pump Drive Engine.
Click here to find pump engines by type (Fuel System & Engine Speed).
NT855-P300 Pump Engine
Power: 224 kW (300 HP) @ 1500 RPM
Fuel System: CMI PT
Compression Ratio: 14.0 : 1
Aspiration: TC & Water-Air Intercooler
Emission Standard: N/A
NT855-P300B Pump Engine
Rated Power: 224 kW @ 1500 RPM
Max. Torque: 224 kW @ 1500 RPM
Fuel System: PT
Aspiration: N/A
Emission Standard: N/A
NT855-P360 Pump Engine
Power: 269 kW (360 HP) @ 1800 RPM
Fuel System: CMI PT
Compression Ratio: 14.0 : 1
Aspiration: TC & Water-Air Intercooler
Emission Standard: N/A
NT855-P400 Pump Engine
Power: 298 kW (400 HP) @ 1800 RPM
Fuel System: CMI PT
Compression Ratio: 14.0 : 1
Aspiration: TC & Water-Air Intercooler
Emission Standard: N/A
NTA855-P360 Pump Engine
Power: 269 kW (360 HP) @ 2100 RPM
Fuel System: CMI PT
Compression Ratio: 14.5 : 1
Aspiration: TC & Water-Air Intercooler
Emission Standard: N/A
NTA855-P360B Pump Engine
Power: 269 kW @ 1800 RPM
Fuel System: CMI PT
Compression Ratio: 14.0 : 1
Aspiration: N/A
Emission Standard: N/A
NTA855-P360C Pump Engine
Rated Power: 268 kW @ 2100 RPM
Max. Torque: 1464 N.m/1500r/min.
Fuel System: PT
Aspiration: N/A
Emission Standard: N/A
NTA855-P400A Pump Engine
Power: 298 kW (400 HP) @ 1500 RPM
Fuel System: CMI PT
Compression Ratio: 14 : 1
Aspiration: TC & Water-Air Intercooler
Emission Standard: N/A
NTA855-P400B Pump Engine
Power: 299 kW (400 HP) @ 1500 RPM
Fuel System: CMI PT
Compression Ratio: 14 : 1
Aspiration: TC & Water-Air Intercooler
Emission Standard: N/A
NTA855-P400C Pump Engine
Power: 298 kW (400 HP) @ 2100 RPM
Fuel System: CMI PT
Compression Ratio: 14 .5: 1
Aspiration: TC & Water-Air Intercooler
Emission Standard: N/A
NTA855-P450 Pump Engine
Power: 336 kW (450 HP) @ 1800 RPM
Fuel System: CMI PT
Compression Ratio: 14 : 1
Aspiration: TC & Water-Air Intercooler
Emission Standard: N/A
NTA855-P450B Pump Engine
Rated Power: 336 kW @ 2100 RPM
Max. Torque: 1831 N.m/1400r/min.
Fuel System: PT
Aspiration: N/A
Emission Standard: N/A
NTA855-P470 Pump Engine
Power: 351 kW (400 HP) @ 1500 RPM
Fuel System: CMI PT
Compression Ratio: 14 : 1
Aspiration: TC & Water-Air Intercooler
Emission Standard: N/A
NTA855-P470B Pump Engine
Power: 351 kW @ 1500 RPM
Fuel System: CMI PT
Compression Ratio: 14.0 : 1
Aspiration: N/A
Emission Standard: N/A
NTA855-P500 Pump Engine
Power: 373 kW (500 HP) @ 1800 RPM
Fuel System: CMI PT
Compression Ratio: 14 : 1
Aspiration: TC & Water-Air Intercooler
Emission Standard: N/A
NTA855-P500B Pump Engine
Power: 373 kW @ 1800 RPM
Fuel System: CMI PT
Compression Ratio: 14.0 : 1
Aspiration: N/A
Emission Standard: N/A
