CCEC QSK19 Generator Drive Engine
CCEC QSK19 series generator drive engine is 6-cylinder inline, 19 liters four-strokes engine with 159 mm (6.25 in) bore and 159 mm (6.25 in) stroke. CCEC QSK19 generator drive engine equipped with PT Fuel System, comes with turbocharger and Air-Air intercooler, with a EURO II post-processor.
The prime power range for 50 Hz generator set (1500 RPM) of CCEC QSK19 series generator drive engine is from 402 kW to 667 kW.
The prime power range for 60 Hz generator set (1800 RPM) of CCEC QSK19 series generator drive engine is from 559 kW to 608 kW.
CCEC generator drive engines have different configurations which have different power output, with code T in the engine model name means turbocharged engine, code TA in the engine model means turbocharge with water-air intercooler and code TAA in the engine model means turbocharge with air-air intercooler. We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.
General Specifications of QSK19 Series
| Engine Type: | 4-Cycle; In-line; 6-Cylinder Diesel |
| Displacement: | 19 L |
| Rated Speed: | 1500 – 1800 RPM |
| Emission Standard: | Euro II |
| Fuel System: | CMS MCRS |
| Standby Power: | 447 – 669 kW @ 1500 – 1800 RPM |
| Prime Power: | 402 – 667 kW @ 1500 – 1800 RPM |
| Bore * Stroke: | 159 mm * 159 mm |
| Dry Weight: | 1900 – 1972 kg |
| Packing Size (L * W * H): | 1695 mm * 985 mm * 1723 mm |
| CCEC QSK19 – Drive Engine Catalogue | ||||||
Engine Model | Rated Power | Aspiration | Engine Model | Rated Power | Aspiration | |
| QSK19-G3-A | 770 HP (574 kW) at 1500 RPM | Air – Air Aftercooled | QSK19-G3-B | 815 HP (608 kW) at 1800 RPM | Air – Air Aftercooled | |
| QSK19-G4-A | 770 HP (574 kW) at 1500 RPM | Charge Air Cooled | QSK19-G4-B | 750 HP (559 kW) at 1800 RPM | Charge Air Cooled | |
| QSK19-G5 | 815 HP (608 kW) at 1800 RPM | Charge Air Cooled | QSK19-G11 | 813 HP (606 kW) at 1500 RPM | Charge Air Cooled | |
| QSK19-G11X | 894 HP (667 kW) at 1500 RPM | Air – Air Aftercooled | QSK19-G12 | 675 HP (503 kW) at 1500 RPM | Low Temperature Aftercooled | |
| QSK19-G13 | 605 HP (451 kW) at 1500 RPM | Charge Air Cooled | QSK19-G14 | 539 HP (402 kW) at 1500 RPM | Charge Air Cooled | |
| QSKTAA19-G3-NR2-A | 770 HP (574 kW) at 1500 RPM | Air – Air Aftercooled | QSKTAA19-G3-NR2-B | 815 HP (608 kW) at 1800 RPM | Air – Air Aftercooled | |
| ——END—— | ||||||
CCEC QSNT Series G-drive Engine
All models of CCEC QSNT Series G-drive Engine.
Click here to find G-drive engines by type (Fuel System & Engine Speed).
QSK19-G3-A G-Drive Engine
Power: 770 HP (574 kW) at 1500 RPM
Fuel System: MCRS
Aspiration: TC & Air to Air Aftercooled
Emission Standard: N/A
QSK19-G3-B G-Drive Engine
Power: 815 HP (608 kW) at 1800 RPM
Fuel System: MCRS
Aspiration: TC & Air to Air Aftercooled
Emission Standard: N/A
QSK19-G4-A G-Drive Engine
Power: 770 HP (574 kW) at 1500 RPM
Fuel System: MCRS
Aspiration: TC & Charge Air Cooled
Emission Standard: N/A
QSK19-G4-B G-Drive Engine
Power: 750 HP (559 kW) at 1800 RPM
Fuel System: MCRS
Aspiration: TC & Charge Air Cooled
Emission Standard: N/A
QSK19-G5 G-Drive Engine
Power: 813 HP (606 kW) at 1500 RPM
Fuel System: MCRS
Aspiration: TC & Charge Air Cooled
Emission Standard: N/A
QSK19-G11 G-Drive Engine
Power: 813 HP (606 kW) at 1500 RPM
Fuel System: MCRS
Aspiration: TC & Air to Air Aftercooled
Emission Standard: N/A
QSK19-G11X G-Drive Engine
Power: 606kW(813BHP)@1500RPM
Fuel System: MCRS
Aspiration: TC & Air to Air Aftercooled
Emission Standard: N/A
QSK19-G12 G-Drive Engine
Power: 675 HP (503 kW) at 1500 RPM
Fuel System: MCRS
Aspiration: TC & Low Temperature Aftercooled
Emission Standard: N/A
QSK19-G13 G-Drive Engine
Power: 605 HP (451 kW) at 1500 RPM
Fuel System: PT
Aspiration: TC & Charge Air Cooled
Emission Standard: Noncertified EPA Tier 3
QSK19-G14 G-Drive Engine
Power: 539 HP (402 kW) at 1500 RPM
Fuel System: PT
Aspiration: TC & Charge Air Cooled
Emission Standard: Noncertified EPA Tier 3
QSKTAA19-G3-NR2-A G-Drive Engine
Power: 770 HP (574 kW) at 1500 RPM
Fuel System: PT
Aspiration: TC & Air to Air Aftercooled
Emission Standard: N/A
QSKTAA19-G3-NR2-B G-Drive Engine
Power: 815 HP (608 kW) at 1800 RPM
Fuel System: PT
Aspiration: TC & Air to Air Aftercooled
Emission Standard: N/A
