CCEC KTA38-P980B Pump Engine

CCEC KTA38-P980(1500 RPM) Pump Engine is V type12-cylinder, 38 liters four-strokes engine with 159 mm (6.25 in) bore and 159 mm (6.25 in) stroke. KTA38-P980 Pump Engine equipped with PT Fuel System, comes with turbocharger and Water-Air intercooler. The maximum power of the CCEC KTA38-P980 pump engine is 980 HP (731 kW) at 1500 RPM, and the torque of the engine at 1500 RPM in this mode is 6293 N.m(4641 lb.ft).

EMAC is a partner of CCEC for many years, we are a professional pump system solution supplier with many years of experience. We provide customers from all over the world with one-stop pump system solutions from pump system design to pump system supply, from installation to commissioning, and from after-sales. Providing sales service support for spare parts supply, EMAC is your reliable pump system partner, providing you with the best value for money and reliable system solutions.

1. Lower oil consumption,Extended stroke,the expansion of the combustion gas more fully, Increase effective efficiency output, the economy is better.
2. Strong power,advanced 4 air valves structure, greater horsepower, air burning more thoroughly, while making low speed torque increase, quicken response speedily, climb strongly.
3. Excellent reliability, with compulsive cold cut articulated pistons, Can bear extreme high mechanical load and heat load, Strength can be comparable with heavy engine.
4. Better emissions, Decorate injector and symmetrical combustion chamber in center, make the cylinder is more homogeneous mixture, burning more fully, lower emissions.
5. Super life, 30% engines 800,000 km without overhaul.
6. Excellence power, Clean burning, use the advanced lean-burn closed loop electronic control system.
7. Excellent cold start performance, equipped with air suction electric preheater and 7.8 kw power starter, completely improve the cold start performance of the engine. Through the arctic village-MoHe of China-36°C extreme low temperature validation.

Technical Specifications

Basic Introduction of CCEC KTA38-P980 Pump Engine

Engine Model:KTA38-P980
Engine Type:12 Cylinders, V Type
Displacement:37.7 L
Rated Speed:1500 RPM
Aspiration Method:Turbocharged
Emission Standard:N/A
Bore*Storke:159 mm × 159 mm
Packing Size(L*W*H):N/A
Weight , Net Dry:3719 kg
Lead Time:15-30 Working Days
Payment Terms:T/T ,L/C
CCEC Pump Engine 620×350 px-6


Engine Model

Maxi. Rating

Aspiration

Curve & Datasheet

Compression Ratio

Fuel System

KT38-P700522 kW (700 HP) @ 1800 RPMTurbochargedC-60215.5 : 1CMI PT
KT38-P780582 kW (780 HP) @ 1800 RPMTurbochargedC-60215.5 : 1CMI PT
KT38-P830619 kW (830 HP) @ 1500 RPMTurbochargedFR-6009715.5 : 1CMI PT
KT38-P1000746 kW (1000 HP) @ 1800 RPMTurbochargedFR15.5 : 1CMI PT
KTA38-P900671 kW (900 HP) @ 1800 RPMTurbocharged & Water-Air IntercoolerC-61414.5 : 1PT-STC
KTA38-P980731 kW (980 HP) @ 1500 RPMTurbocharged & Water-Air IntercoolerFR14.5 : 1CMI PT
KTA38-P980B731 kW (980 HP) @ 1500 RPMTurbochargedC-62414.5 : 1CMI PT
KTA38-P1080813 kW (1090 HP) @ 1500 RPMTurbocharged & Water-Air IntercoolerFR-685214.5 : 1CMI PT
KTA38-P1100821 kW (1100 HP) @ 1800 RPMTurbocharged & Water-Air IntercoolerC-61614.5 : 1PT-STC
KTA38-P1200A895 kW (1200 HP) @ 1500 RPMTurbocharged & Water-Air IntercoolerFR-692514.5 : 1CMI PT
KTA38-P1200B895 kW (1200 HP) @ 1800 RPMTurbocharged & Water-Air IntercoolerFR-695414.5 : 1CMI PT
KTA38-P1200C821 kW (1100 HP) @ 1800 RPMTurbochargedC-61713.9 : 1CMI PT
KTA38-P1250933 kW (1250 HP) @ 1800 RPMTurbocharged & Water-Air IntercoolerC-61115 : 01PT-STC
KTA38-P1300970 kW (1300 HP) @ 1500 RPMTurbocharged & Water-Air IntercoolerC-62414.5 : 1CMI PT
KTA38-P14001045 kW (1400 HP) @ 1800 RPMTurbocharged & Water-Air IntercoolerC-695613.9 : 1CMI PT
KTA38-P1400B1045 kW (1400 HP) @ 1800 RPMTurbochargedC-64213.9 : 1CMI PT
KTA38-P14901112 kW (1490 HP) @ 1800 RPMTurbocharged & Water-Air IntercoolerFR13.9 : 1CMI PT
——END——



General Infomation of CCEC KTA38-P980B Pump Engine

Engine ModelKTA38-P980Standby PowerN/A
Maxi. Rating731 kW @ 1500 r/minEmission StandardN/A
Curve & DatasheetC-624Peak TorqueN/A
Compression Ratio14.5:1Displacement37.7 L
Type12 Cylinders, V TypeBore*Storke159 mm × 159 mm
Fuel SystemPTDry Weight Fan Hub to Flywheel Engine3719 kg
AspirationTurbochargedWet Weight(Fan Hub to Flywheel Engine)4016 kg
ConfigurationD233020DX02Packing Size(L*W*H)N/A
CPL Code Revision0851Firing Order1-5-3-6-2-4

Performance Data of CCEC KTA38-P980B Pump Engine

Idle625 RPMCrankshaft Thrust Bearing Load — Maximum Continuous3336 N
Maximum No-Load Governed Speed1800 RPMMaximum Allowable Power From Front of CrankshaftN/A
Crankshaft Thrust Bearing Load — Maximum Intermittent6672 NMaximum Allowable Power From Accessory Drive6 kW
Estimated Free Field Sound Pressure Level— Right Side
(At 50 ft(15m) and Full Load Governed Speed (Excludes Noise From Intake.Exhaust. Cooling System and Driven Components)
82 dBA
Estimated Free Field Sound Pressure Level— Left Side
(At 50 ft(15m) and Full Load Governed Speed (Excludes Noise From Intake.Exhaust. Cooling System and Driven Components)
84.5 dBA
Estimated Free Field Sound Pressure Level— Front
(At 50 ft(15m) and Full Load Governed Speed (Excludes Noise From Intake.Exhaust. Cooling System and Driven Components)
84 dBA
Estimated Free Field Sound Pressure Level— after side
(At 50 ft(15m) and Full Load Governed Speed (Excludes Noise From Intake.Exhaust. Cooling System and Driven Components)
N/A
——END——



Engine Performance Data CCEC KTA38-P980B Pump Engine

Maximum power
Maximum power pointMaximum torque point
Engine Speed (r/min)1500N/A
Output Power (kW)713N/A
Torque (N·m)6293N/A
Fuel Line Rated Point Pressure (kPa)817N/A
Intake Manifold Pressure (kPa)118N/A
Mean Effective Pressure (kPa)1551N/A
Average Piston Speed (m/s)7.9N/A
Friction Power (kW)86N/A
Inlet Flow (L/s)920N/A
Dry Exhaust Pipe-Extraction Flow  (L/s)2634N/A
Dry Exhaust Pipe-Discharge Temperature ()513N/A
Dry Exhaust Pipe-Ambient Heat Dissipation (kW)137N/A
Dry Exhaust Pipe-Heat Dissipation Of Coolant (kW)594N/A
Engine Cooling Water Flow (L/s)26N/A
——END——



System Technical Data of CCEC KTA38-P980B Pump Engine

Exhaust SystemMaximum Exhaust Back Pressure10 kPa
Recommended Exhaust Piping Size (Inner Diameter)152 mm
Air Intake SystemMaximum Intake Resistance For Light Duty Dry Air Filters— Clean Element3.74 kPa
Maximum Intake Resistance For Light Duty Dry Air Filters— Dirty Element6.23 kPa
Minimum Dust Holding Capacity Allowed With Heavy Duty Air Filter53 g /L/s
Lubrication SystemOil Pressure – At Low Idle Speed138 kPa
Oil Pressure – At Rated Speed310-448 kPa
Oil Flow Rate At Rated Speed469.4 L/min
Maximum Oil Temperature Allowed124.0
Cooling SystemWater Capacity Of Engine Internal Coolant118 L
Maximum Engine External Cooling Water Resistance34.5 kPa
The Maximum Cooling Water Drop Above The Engine Crankshaft Centerline7.6 m
Standard Thermostat Temperature Range80-90
Maximum Cooling Water Pressure (Except Pressure Cap)241 kPa
The Minimum Allowable Pressure Of The Pressure Cap48 kPa
Maximum Temperature Allowed In The Top Tank93.3
Minimum Recommended Temperature For Top Tank71.1
The Minimum Allowable Water Refill Rate18.9 L/min
The Maximum Initial Water Refill Time Allowed5 min
The Minimum Allowable Cooling Water Expansion Volume Occupies The System Volume5%
Maximum Allowed Exhaust Time25min
Minimum Coolant Level Reduction Volume Allowed20.8 L
——END——


Scopes of Supply of CCEC KTA38-P980B Pump Engine

Air Intake System1. Air Intake ManifoldExhuast System1. Exhuast Manifold
2. Water-air Intercooler2. Turbocharger
3. N/A3. Exhuast Elbow
Fuel System1. Fuel transfer pumpStarting System1. Starter motor
2. High-pressure fuel pump2. Starter rely
3. Fuel Filter3. N/A
Charging System1. Charging alternatorEngine Shut-Down System1. Engine fuel shut-off solenoid
Lubricating System1. Oil pumpCooling System1. Water pump
2. Oil filter2. Engine Fan
3. N/A3. Standard radiator
Power Output System1. FlywheelEngine Mounting System1. Engine Mouting Bracket
2. Standard flywheel housing2. N/A
Engine Auiliary Accessories1. Air compressor
2. Power steering pump
——END——

Optional Accessories of CCEC KTA38-P980B Pump Engine

Air Intake System1. Air Intake Pre-heaterExhuast System1. Muffler & Bellows
2. Air Intake Pre-filter2. Flame Trap
3. Air Filter Alarm System3. Spark Arrestor Type Muffler & Bellows
4.N/A4. DPF System
Fuel System1. Coarse FilterEngine Auiliary Accessories1. Hydraulic Oil Pump
2. Fuel Pre-heater2. Hydraulic Cluch
Starting System1. Manual Magnetic DC ContactorControl System1. Engine Monitor
2. Dual Ears Flywheel Housing2.Engine Protection System with Alarm System
3. Spring Starter Motor3. Machanical Engine Control Lever System
4. Air Starter Motor4. Electric Engine Control Lever System
5. Hydraulic Starter Motor5. N/A
6. Manual Magnetic DC Contactor6. N/A
Power Output System1. Gear Reduction GearboxCooling System1. Coolant Pre-heater
2. Reverse Gear Box2. Jacket Water Heater
Lubricating System1. Oil Pre-heaterEngine Mounting System1. Shock Absorber Pad
——END——

As part of EMAC, PumpMac focusing on water pump set related business, from pump drive engine, to WPT PTO, from complete engine power pack to complete water pump set, from NFPA20 standard fire fighting pump accessories to fire pump drive package, from explosion proof accessories to complete explosion-proof water pump set, PumpMac provides professional one-stop solution for everything customer needed for water pump set industry.
For more information of our pump drive power pack and complete water pump set products, you are welcome to visit PumpMac homepage: www.pumpmac.com



Modifiable Components of CCEC KTA38-P980B Pump Engine

Air Intake System1. Installation position of air filterExhuast System1. Can modify installation position and direction of
2. Upgrade to  heavy-duty type air fitlerturbocharger
3. N/A2. Water-cooled exhuast manifold
4. N/A3. Water-cooled turbocharger
Fuel System1. Upgrade to fuel fitler that integrated with fuel transferStarting System1. 12V starter motor for 12v electric system
pump and fuel pre-hearter2. Upgrading to specified brand and speicifications of
2. N/Astarter motor
Charging System1. 12V charging alternator for 12v electric systemEngine Shut-Down System1. 12V solenoid for 12v electric system
2. Explosion-proof charging alternator2. Explosion-proof solenoid
3. Upgrading to specified brand and speicifications of3. N/A
charging alternator4. N/A
Lubricating System1. Oil Pan positionCooling System1. Can modify engine fan into blower fan or suction fan
2. Number of dipstick2. Can modify central position of engine cooling fan
3. Position of dipstick can choose from 6 positions3. Can choose type of engine fan from mechanical type or
4. Can modify oil filter to be remote installationelectric type
Power Output System1. Can modify size of flywheel housing and flywheel.Engine Mounting System1. Can modify engine mouting bracket.
2. Dual-ear flywheel housing (For twin-starter system)2. N/A
3. Some of models can modify flywheel housing into PTO3. N/A
integrated type.4. N/A
4. Engine have connecting port of PTOs, that able to5. N/A
provide power output.6. N/A
Engine Auiliary Accessories1. All of auxiliary system can choose specified brands and
specifications.
2. Additional auxiliary systems can be added for special
applications.
——END——

Note: All Above Data are Just for Referenece, All Data Might Change Without Notices or Update, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
