CCEC KTA38 Pump Drive Engine
CCEC K38 Series Pump Drive Engine is V type 12-cylinder, 37.7 liters four-strokes engine with 159 mm (6.25 in) bore and 159 mm (6.25 in) stroke. K38 Series Pump Drive Engine equipped with CMS PT Fuel System, comes with turbocharger. The power range of CCEC K38 series pump drive engine is from 700 HP to 1490 HP (522 kW to 1112 kW). The torque range of the K38 Series Pump Drive Engine is 3047 N.m to 6293 N.m.
EMAC is a partner of CCEC for many years, we are a professional pump system solution supplier with many years of experience. We provide customers from all over the world with one-stop pump system solutions from pump system design to pump system supply, from installation to commissioning, and from after-sales. Providing sales service support for spare parts supply, EMAC is your reliable pump system partner, providing you with the best value for money and reliable system solutions.
General Specifications of KTA38 Series
| Engine Type: | 4 Cycle , 60° Vee , 12 Cylinder |
| Displacement: | 38 L |
| Rated Speed: | 1500 – 1800 RPM |
| Rated Power / Speed: | 522 – 1112 kW @ 1500 – 1800 RPM |
| Peak Torque: | 3847 – 5544 N.M @ 1500 – 1800 RPM |
| Fuel System: | CMI PT / PT-STC |
| Aspiration Method: | Turbocharged & Water-Air Intercooler |
| Bore * Stroke: | 159 mm * 159 mm |
| Basic Engine (L * W * H): | 2260 mm * 1339 mm * 2332 mm |
| Wet Weight: | 3719 – 4809 kg |
Engine Model | Rated Power | Peak Torque | Engine Model | Rated Power | Peak Torque | |
| KT38-P700 | 522 kW (700 HP) @ 1800 RPM | 3047 N.m @ 1500 RPM | KT38-P780 | 582 kW (780 HP) @ 1800 RPM | 3481 N.m @ 1300 RPM | |
| KT38-P830 | 619 kW (830 HP) @ 1500 RPM | 3941 N.m @ 1500 RPM | KT38-P1000 | 746 kW (1000 HP) @ 1800 RPM | 3956 N.m @ 1800 RPM | |
| KTA38-P900 | 671 kW (900 HP) @ 1800 RPM | 3847 N.m @ 1500 RPM | KTA38-P980 | 731 kW (980 HP) @ 1500 RPM | 6293 N.m @ 1500 RPM | |
| KTA38-P980B | 731 kW (980 HP) @ 1500 RPM | 6293 N.m @ 1500 RPM | KTA38-P1080 | 805 kW (1080 HP) @ 1500 RPM | 5178 N.m @ 1500 RPM | |
| KTA38-P1100 | 821 kW (1100 HP) @ 1800 RPM | 4354 N.m @ 1800 RPM | KTA38-P1200A | 895 kW (1200 HP) @ 1500 RPM | 5696 N.m @ 1500 RPM | |
| KTA38-P1200B | 895 kW (1200 HP) @ 1800 RPM | 4748 N.m @ 1800 RPM | KTA38-P1200C | 895 kW (1200 HP) @ 1800 RPM | 4747 N.m @ 1800 RPM | |
| KTA38-P1250 | 933 kW (1250 HP) @ 1800 RPM | 4950 N.m @ 1800 RPM | KTA38-P1300 | 970 kW (1300 HP) @ 1500 RPM | 6172 N.m @ 1500 RPM | |
| KTA38-P1400 | 1045 kW (1400 HP) @ 1800 RPM | 5544 N.m @ 1800 RPM | KTA38-P1400B | 1045 kW (1400 HP) @ 1800 RPM | 5544 N.m @ 1800 RPM | |
| KTA38-P1490 | 1112 kW (1490 HP) @ 1800 RPM | 5544 N.m @ 1800 RPM | ||||
| ——END—— | ||||||
CCEC KTA38 Series Pump Drive Engine
This list including all models of CCEC KTA38 Series Pump Drive Engine.
Click here to find pump engines by type (Fuel System & Engine Speed).
KTA38-P1250 Pump Engine
Rated Power: 933 kW (1250 HP) @ 1800 RPM
Fuel System: PT-STC
Compression Ratio: 15.0 : 1
Aspiration: Turbocharged & Water-Air Intercooler
Emission Standard: N/A
KT38-P700 Pump Engine
Power: 522 kW (700 HP) @ 1800 RPM
Fuel System: PT
Compression Ratio: 5.5:1
Aspiration: Turbocharged
Emission Standard: N/A
KT38-P780 Pump Engine
Power: 582 kW (780 HP) @ 1800 RPM
Fuel System: PT
Compression Ratio: 15.5:1
Aspiration: Turbocharged
Emission Standard: N/A
KT38-P830 Pump Engine
Rated Power: 619 kW (830 HP) @ 1500 RPM
Fuel System: CMI PT
Compression Ratio: 15.5 : 1
Aspiration: Turbocharged
Emission Standard: N/A
KT38-P1000 Pump Engine
Rated Power: 746 kW (1000 HP) @ 1800 RPM
Fuel System: CMI PT
Compression Ratio: 15.5 : 1
Aspiration: Turbocharged
Emission Standard: N/A
KTA38-P900 Pump Engine
Rated Power: 671 kW (900 HP) @ 1800 RPM
Fuel System: PT-STC
Compression Ratio: 14.5 : 1
Aspiration: TC & Water-Air Intercooler
Emission Standard: N/A
KTA38-P980 Pump Engine
Rated Power: 731 kW (980 HP) @ 1500 RPM
Fuel System: CMI PT
Compression Ratio: 14.5 : 1
Aspiration: TC & Water-Air Intercooler
Emission Standard: N/A
KTA38-P980B Pump Engine
Power: 731 kW (980 HP) @ 1500 RPM
Fuel System: CMI PT
Compression Ratio: 14.5 : 1
Aspiration: TC & Water-Air Intercooler
Emission Standard: N/A
KTA38-P1080 Pump Engine
Rated Power: 805 kW (1080 HP) @ 1800 RPM
Fuel System: CMI PT
Compression Ratio: 14.5 : 1
Aspiration: TC & Water-Air Intercooler
Emission Standard: N/A
KTA38-P1100 Pump Engine
Rated Power: 821 kW (1100 HP) @ 1800 RPM
Fuel System: PT-STC
Compression Ratio: 14.5 : 1
Aspiration: TC & Water-Air Intercooler
Emission Standard: N/A
KTA38-P1200A Pump Engine
Rated Power: 895 kW (1200 HP) @ 1500 RPM
Fuel System: CMI PT
Compression Ratio: 14.5 : 1
Aspiration: TC & Water-Air Intercooler
Emission Standard: N/A
KTA38-P1200B Pump Engine
Rated Power: 895 kW (1200 HP) @ 1800 RPM
Fuel System: CMI PT
Compression Ratio: 14.5 : 1
Aspiration: TC & Water-Air Intercooler
Emission Standard: N/A
KTA38-P1200C Pump Engine
Power: 895 kW (1200 HP) @ 1800 RPM
Fuel System: PT
Compression Ratio: 13.9 : 1
Aspiration: Turbocharged
Emission Standard: N/A
KTA38-P1300 Pump Engine
Rated Power: 970 kW (1300 HP) @ 1500 RPM
Fuel System: CMI PT
Compression Ratio: 14.5 : 1
Aspiration: TC & Water-Air Intercooler
Emission Standard: N/A
KTA38-P1400 Pump Engine
Rated Power: 1045 kW (1400 HP) @ 1800 RPM
Fuel System: PT-STC
Compression Ratio: 13.9 : 1
Aspiration: TC & Water-Air Intercooler
Emission Standard: N/A
KTA38-P1400B Pump Engine
Power: 1045 kW (1400 HP) @ 1800 RPM
Fuel System: PT
Compression Ratio: 13.9 : 1
Aspiration: Turbocharged
Emission Standard: N/A
KTA38-P1490 Pump Engine
Rated Power: 1112 kW (1490 HP) @ 1800 RPM
Fuel System: CMI PT
Compression Ratio: 13.9 : 1
Aspiration: TC & Water-Air Intercooler
Emission Standard: N/A
